Product Release

MINISFORUM Announce Venus Series UM560

MINISFORUM Announce Venus Series UM560

UM560 is the first AMD mini PC with Alt-Mode USB-C and the world’s first mini PC that comes with GaN power supply. It is a multi-purpose mini computer designed for use in a variety of solutions, such as a home office, media centre/HTPC, printer management PC, digital signage, or mass-deployment enterprise IT solution.

https://store.minisforum.com/products/um560

Four type options:

  • Barebone : $359
  • 8GB RAM+256GB SSD : $439
  • 16GB RAM+256GB SSD : $479
  • 16GB RAM+512GB SSD : $499
  • 32GB RAM+512GB SSD : $569

Powerful Processor & Graphics

UM560 features and benefits depend on system configurations, the power of AMD Ryzen™ 5 5625U (6 cores/12 threads. Base Clock 3.3 GHz, up to 4.3 GHz) and AMD Radeon™ Graphics (1800 MHz graphics frequency) . Explore endless computing possibilities.

GaN power supply

UM560 is the world’s first mini PC that comes with GaN power supply which is safer, faster and more portable.


a. One for All: The 65W charger can auto detect the devices and compatible with mainstream charging protocols that can charge for a series of notebooks, for iPhones and Android phones, tablets and more.
b. Perfect for Business Travel: Thanks to GaN tech, the 65W power adapter is more than 60% smaller than traditional silicone chargers, less bulky to be carried in your pocket.
c. Fast Speed Charging: The USB-C GaN charger delivers up to 93% conversion rate, much higher efficiency than a standard charger.

Quad 4K Displays

UM560 supports ultra-realistic 4K UHD visuals with incredible clarity. The quad 4K display solution provides you with maximum productivity at work to improve the efficiency.

Minisforum UM560

CPU

AMD Ryzen™ 5 5625U, 6 Cores/12 Threads
(Total L1 Cache 384KB , Total L2 Cache 3MB , Total L3 Cache 16MB , Base Clock 3.3 GHz, up to 4.3 GHz)

GPU

AMD Radeon™ Graphics (Graphics Frequency 1800 MHz)

Memory

DDR4 8GB×2 Dual channel (SODIMM Slots×2)

Supports a maximum of 64GB(32GB x 2) of DDR4

Storage

M.2 2280 512GB PCIe SSD

Storage Expansion

1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)

Wireless Connectivity

M.2 2230 WIFI Support (Wi-Fi,BlueTooth)

Video Output

① HDMI (4K@60Hz) x2

② USB-C(Display , 4K@60Hz , In Front)

Audio Output

HDMI , 3.5mm Audio Jack

Ports & Buttons

1 * RJ45 2.5 Gigabit Ethernet Port

2 * USB 2.0 Port

2 * USB 3.2 Port(Gen2)

1 * USB-C (Alt-Mode) *support PD3.0/DP1.4/DATA *not support USB2.0 ,In Back

1 * USB 3.2 Gen2 Type-C (Data Only , In Front)

1 * USB 3.2 Type-C (support DP1.4 ,4K@60Hz)

1 * Clear CMOS

1 * DMIC

1 * Power Button

Power

65W USB-C Power Delivery adapter (Included)

System

Windows 11

Product Dimension

12.8×12.66×4.25 cm

Package Dimension

Launch Date

June-2022

Package Content

1 * UM560

1 * Power Adapter

1 * HDMI Cable

1 * Mounting Bracket

1 * User Manual

1 * Computer Stand
