Minisforum UM300 / UM250 Mini PC
Regular price $349.00 Sale price $299.00【Superior Performance】UM300 Mini PC pre-install Windows 10 Pro pre-installed (supports Linux and Chromium OS), AMD Ryzen 3 3300U , 4 Cores/4 Threads (Total L2 Cache 2MB , Total L3 Cache 4MB , Base Clock 2.1 GHz , up to 3.5 GHz) processor Brings a shocking visual effect.
【Large capacity】DDR4 8GB×2 Dual channel (SODIMM Slots×2, memory can be converted to 16GB each) + M.2 2280 128GB SATA SSD storage (up to 2TB upgradeable).
【Expandable Storage】Designed with Dual channel (SODIMM Slots×2),M.2 2280 SATA SSD slot ×1,2.5' SATA HDD Slot (SATA 3.0 6.0Gb/s) ×1,witn press and pop-up clasp, which makes it easy to install additional memory/SSD/HDD.
【Triple Display Output】Installed with Radeon Vega 6 graphics (graphics frequency 1200 MHz), drives up to 3 independent displays with incredible clarity and maximum productivity in your workflow with excellent triple display solutions using HDMI 2.0
【What you get】 1x UM300 mini PC, 1x bracket, 1x mini DP cable, 1x HDMI cable (60 cm), 1x power supply, 1x manual. Note: The Mini DP connector does not support Mini DP to DVI / HDMI adapter, only Mini DP to VGA adapter. ***Each product includes LIFETIME technical support, a worry-free 30-day return and a 1-year after-sales service
【Warranty & Service】: one year warranty, one month free return, get after-sale service support within 7X24 hours.
-
Features and Benefits
-
UM300 SPEC
-
UM250 SPEC
-
Test Report
AMD Ryzen 3 3300U Windows 10 Home Mini PC
UM300 mini PC is equipped with the AMD Ryzen 3 3300U processor.
It delivers up to 50% better performance than previous generation processors and smoothly handles heavy compute tasks,
and it performs daily PC work smoothly with its reliable performance. The small body achieves the same performance as a desktop.
Upgrade-friendly Design
Versatile Storage Options
Flexible Dual-channel
The UM300 mini PC is designed with press and pop-up clasp, so you can easily install additional memory, SSD, HDD.To add more, push down the positions shown with both hands at the same time to pop out the cover.
M.2 2280 128GB SATA SSD is pre-installed and can be replaced with up to 2TB SSD. Supporting ultra-fast SSDs, you will be able to run the operating system and games faster and more efficient.
Memory has dual channel (SODIMM Slot x2), 8GB 2400MHz RAM is pre-installed and can be updated to 32GB each. The data transmission speed is improved by adding memory and speed is faster than single channel.
Features & Functions for UM300
Multiple Applications Support
UM300 Mini PC is a wisdom idea for multiple commercial applications. It can be widely used for Home Theater, Office Work, Meeting, Education, Projector Monitoring, Host, Printer, Media Equipment, Digital Signboard etc.
High Definition 4k Dual Display
With high definition 4k dual display, UM300 mini pc provides you more frequent movie experience and make your work more efficient via HDMI port, mini display port and USB-C port.
Large Capacity and Extended Storage
- Memory: DDR4 8GB×1 Dual channel (SODIMM Slots×2)
- Storage: M.2 2280 128GB SATA SSD
- Storage Expansion: 1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
Package Included
- 1* UM300 MINI PC
- 1* Power Adapter
- 1* HDMI Cable
- 1* DP Cable
- 1* Wall Mount
- 1* English Manual
Buttons & Ports for UM300 Mini PC
- 1x HDMI 2.0
- 1x DisplayPort
- 2x RJ45 Port
- 1x Clear CMOS
- 1x Power Switch
- 1x USB-C
- 1x 3.5mm Audio Jack
- 1x DC Port (19V/3A)
- 1x Reset Hole
- 3x USB 3.1(Gen2, blue)
- 1x Digital Microphone Jack
- 1x USB 3.1 (Gen1, yellow, shutdown charge)
Wall Mount Included for Saving Space
The Wall Mount is included in the package, you could fix it on your back of the TV or monitor, which can save your room and make your desktop tidy and neat.
MINISFORUM DeskMini UM300 Mini PC
Processor
AMD Ryzen™ 3 3300U , 4 Cores/4 Threads
(Total L2 Cache 2MB , Total L3 Cache 4MB , Base Clock 2.1 GHz , up to 3.5 GHz)
GPU
Radeon™ Vega 6 Graphics (Graphics Frequency 1200 MHz)
Memory
DDR4 8GB Dual channel (SODIMM Slots×2)
Storage
M.2 2280 128GB/256GB/512GB SATA SSD
Storage Expansion
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
Wireless Connectivity
M.2 2230 WIFI Support (Intel® WIFI6 AX200 , BT5.0 pre-install)
Video Output
Audio Output
HDMI 2.0 , DisplayPort , USB-C Port , 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×2, USB3.1 Port×1 (Gen1, 2.0A Max output, shutdown charging, Yellow),
USB3.1 Port×3 (Gen2 , Blue), USB-C Port×1 (Gen2), Digital MIC×1, Clear CMOS
Ports & Buttons
2 * USB 3.0 Port
1 * Display Port
1 * LAN port
1 * Port Input
1 * HDMI Port
1 * Kensington Lock
1 * Power Button
1 * Reset Button
1 * Reset Hole
1 * Digital MIC
2 * USB 3.1
1 * USB-C Port
Power
DC 19V/3A (adapter included)
Features
RTC Wake Up/Wake on Lan/Power On Auto Power On (BIOS setting)/Network Boot
System
Windows 10 Pro
Launch Date
July-20
Product Dimension
128×127×46mm
Package Dimension
158×158×100mm
Net Weight
0.55/KGS
Gross Weight
1.40/KGS
Package Cotent
1 * MINISFORUM DeskMini UM300 Mini PC
1 * Power Adapter
1 * DP Cable
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
MINISFORUM DeskMini 250 Mini PC
Processor
AMD Ryzen™ 5 PRO 2500U , 4 Cores/8 Threads
(Total L2 Cache 2MB , Total L3 Cache 4MB , Base Clock 2.0 GHz , up to 3.6 GHz)
GPU
Radeon™ Vega 8 Graphics (Graphics Frequency 1100 MHz)
Memory
DDR4 8GB Dual channel (SODIMM Slots×2)
Storage
M.2 2280 128GB/256GB/512GB SATA SSD
Storage Expansion
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
Wireless Connectivity
M.2 2230 WIFI Support (Intel® WIFI6 AX200 , BT5.1 pre-install)
Video Output
Audio Output
HDMI 2.0 , DisplayPort , USB-C Port , 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×2, USB3.1 Port×1 (Gen1, 2.0A Max output, shutdown charging, Yellow), USB3.1 Port×3 (Gen2 , Blue), USB-C Port×1(Gen2) Digital MIC×1, Clear CMOS
Ports & Buttons
2 * USB 3.0 Port
1 * Display Port
1 * LAN port
1 * Port Input
1 * HDMI Port
1 * Kensington Lock
1 * Power Button
1 * Reset Button
1 * Reset Hole
1 * Digital MIC
2 * USB 3.1
1 * USB-C Port
Power
DC 19V/3A (adapter included)
Features
RTC Wake Up/Wake on Lan/Power On Auto Power On (BIOS setting)/Network Boot
System
Windows 10 Pro
Launch Date
July-20
Product Dimension
128×127×46mm
Package Dimension
158×158×100mm
Net Weight
0.55/KGS
Gross Weight
1.40/KGS
Package Cotent
1 * MINISFORUM DeskMini UM250 Mini PC
1 * Power Adapter
1 * DP Cable
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Customer Reviews
Minisforum EliteMini UM700
Regular price $539.00【Excellent Processor and OS】Equipped with AMD Ryzen™ 7 3750H and Windows 10 Pro pre-installed, bringing excellent experience of the Internet and Office applications, such as TV, Media player, Monitor, Projector, Printer and other equipment.
【Silent Fan & & Unlock】Very Silent with great performance, this mini pc adopts energy-efficient components and good cooling system, there is little noise during operating and plays 4K video smoothly. An ideal mini pc for home office, Internet surfing, watching movies, or simply browsing the web.
【Large Capacity & Friendly-upgraded】UM700 is 8GB DDR4 Dual channel (SODIMM Slots×2) + 256GB SSD + 2.5 inch SATA HDD, M.2 2230 WIFI Support (Intel® WIFI6 AX200 , BT5.1 pre-install), Triple Screens ensure smooth navigation, responsive work processes and comfortable handling of apps and files. It's the base operating frequency 2.3 GHz/s rising to a 4.0 GHz in burst mode.
-
Meet UM700
-
Features
-
Specification
-
FAQs
EliteMini UM700
Minisforum EliteMini UM700 is an ultra-small high-performance mini PC. Adopting the powerful AMD Ryzen™ 7 3750H processor, 4 Cores/8 Threads, equipped with Radeon™Vega 10 Graphics 10 Cores Graphics, The powerful performance allows you to freely enjoy unparalleled fluency and unbelievable quick response speed.
EliteMini UM700 is the perfect choice for you. Incredibly space-saving yet boasting high performance, it can easily replace your personal clunky traditional PC.
Core Features
Powerful Processor and Graphics
EliteMini UM700 is a powerful mini PC which comes with the AMD Ryzen™ 7 3750H CPU up to 4.0 GHz, 4 cores 8 threads, total cache 4MB, equipped with Radeon™ RX Vega 10 10 cores Graphics with frequency up to1400 MHz.
EliteMini UM700 backed up by AMD Ryzen™ 7 3750H CPU with powerful GPU Radeon™ RX Vega 10, For most advanced content creators, it lets you finish the work smoothly, easily and effectively.
Backed up by Radeon™ RX Vega 10 Graphics, Minisforum EliteMini UM700 can be a high-performing pro-gaming mini PC, which can run games at significantly higher frame rates, enjoy the game without hindrance.
The following table shows the benchmarking results in some games (1920 × 1080 resolution):
Testing Environment：CPU: AMD Ryzen™ 7 3750H; Monitor: 1920*1080 60Hz; RAM: DDR4 8G x2; Radeon™ RX Vega 10 Graphics
Upgrade-friendly
Dual channel (SODIMM Slots×2)
Dual-channel RAM is a version of multi-channel memory. All versions of multi-channel RAM increase data transmission speed by adding more communication channels between memory and memory controller. The transmission speed is faster than single channel.
Different Internal Storage Options
EliteMini UM700 supports different types of storage expansions — 2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s) and M.2 2280 NVMe SSD Slot (support up to 2TB), you can mix and match between HDD and SSD to enjoy the fun of DIY.
a. Dual channel (SODIMM Slots×2)
b. M.2 2280 NVMe SSD Slot ×1
c. 2.5 inch SATA HDD Slot ×1
Triple Display Supports
EliteMini UM700 drives up to three independent displays with incredible clarity and maximum productivity in your workflow with excellent triple display solutions using HDMI, DisplayPort as well as USB-C output.
Faster Intel Wi-Fi 6
Intel® AX200 WLAN belongs to the AX-22260 family, code-named "Cyclone Peak", supports WiFi 6 technology (802.11ax) standard, integrates Bluetooth 5.0 module, supports 5GHz / 2.4GHz dual frequency and multi-user 2x2 MIMO (MU-MIMO), peak bandwidth It is 2.4Gbps, which is at least 37% higher than the current 802.11ac rate. WiFi5 802.11ac standard supports 160Mhz bandwidth.
Dual RJ45 Ports
EliteMini UM700 comes with two Gigabytes LAN ports which provide you much more network usage, such as software router(OpenWRT/DD-WRT/Tomato, etc.), firewall, NAT and network isolation, etc.
Unleashing Higher Performance
The AMD Ryzen™ 7 3750H processor has a default TDP of 15W, and the power consumption of 15W limits its performance. AMD® officially allows a maximum power consumption of 35W. Of course, extremely clever optimization is required to achieve this goal. Therfore, we have made the following efforts:
a. Use a larger turbofan.
b. Add a thick thermally conductive copper tube and spray graphene on the heat dissipation module.
C. Equipped with power adapter, the maximum power consumption is 65W.
Easy Installation
Features & Functions for UM700
High Definition 4K Triple Displays
UM700 Mini PC brings you ultra-realistic 4K UHD visuals with incredible clarity and maximum productivity in your workflow with excellent triple display solutions using HDMI, DisplayPort as well as USB-C output. You can connect multiple screens in the same time for more efficiency.
Flexible DIY Upgrade-Friendly
Our Mini PC is designed with a press and pop-up clasp, which makes it easy to install additional memory, SSD, HDD and Wi-Fi.
Multiple Application Options
Great choice for multiple commercial and industrial network activities. It's a ideal helper which can be widely used for Home Theater, Office Work, Meeting, Education, Projector Monitoring, Host, Printer, Media Equipment, Digital Signboard etc.
Ports & Button for UM700:
- RJ45 Gigabit Ethernet Port×2
- USB3.1 Port×1 (Gen1, Yellow)
- USB3.1 Port×3 (Gen2 , Blue)
- USB-C Port×1(Gen2)
- HDMI 2.0×1
- Display Port×1
- Audio Jack x 1
- Digital MIC×1
- Clear CMOS
Small but Powerful Mini PC
- AMD Ryzen™ 7 3750H
- Radeon™ RX Vega 10 Graphics
- Silent fan & Unlock TDP 25W/35W
- Windows 10 Pro & Wi-Fi 6 pre-installed
- DDR4 8GB×1 Dual channel (SODIMM Slots×2)
- Upgrade-friendly
- Support 3 monitors at the same time streaming in 4K@60Hz
- 2.5-inch SATA SSD
- M.2 2280 NVMe SSD (PCle 4X)
Wall Mount Support
The wall mount bracket is already included in the package. And it's easy to be fixed on the back of the monitor or TV. Saving your space and keep your desk tidy.
Minisforum DeskMini UM700
Processor
AMD Ryzen™ 7 3750H , 4 Cores/8 Threads
(Total L2 Cache 2MB , Total L3 Cache 4MB , Base Clock 2.3 GHz , up to 4.0 GHz)
GPU
Radeon™ RX Vega 10 Graphics (Graphics Frequency 1400 MHz)
Memory
DDR4 8×2 Dual channel (SODIMM Slots×2)
Storage
M.2 2280 128GB/256GB/512GB PCIe SSD
Storage Expansion
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
Wireless Connectivity
M.2 2230 WIFI Support (Intel® WIFI6 AX200 , BT5.1 pre-install)
Video Output
① HDMI 2.0 (4K@60Hz)
② DisplayPort (4K@60Hz)
③ USB-C Port (4K@60Hz)
Audio Output
HDMI 2.0, DisplayPort, USB-C Port, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×2, USB3.1 Port×1 (Gen1, 2.0A Max output, shutdown charging, Yellow), USB3.1 Port×3 (Gen2 , Blue), USB-C Port×1 (Gen2), Digital MIC×1, Clear CMOS
Ports & Buttons
2 * RJ45 Gigabit Ethernet Port
1 * USB3.1 Port (Gen1, Yellow)
1 * USB3.1 Port (Gen2 , Blue)
1 * USB-C Port (Gen2)
1 * HDMI 2.0
1 * DisplayPort
1 * Audio Jack
1 * Digital MIC
1 * Clear CMOS
Power
DC 19V/3.42A (adapter included)
System
Windows 10 Pro
Lunch Time
December-20
Product Dimension
128×127×46mm
Package Dimension
158×158×100mm
Net Weight
0.50/KGS
Gross Weight
1.40/KGS
Package Cotent
1 * Minisforum DeskMini UM700
1 * Power Adapter
1 * HDMI Cable
1 * USB Cable
1 * Mounting Bracket
1 * User Manual
Q1. When will UM700 be shipped and how long to ship to me?
A: Hi, as UM700 is one of our pre-order product, the shipping time will be in December. And it usually takes 3~7 business day to deliver.
Q2. Where it shipped from?
A: Hi, as DMAF5 is our new product, it will be shipped from China.
Q3. If it's Windows OS pre-installed?
A: Hi, yes, UM700 is Windows 10 Pro pre-installed.
Q4. Will I need to pay custom duties or taxes on my orders?
A: Items shipped from all our warehouses are not subject to export taxes. However, if you are shipping an item from one county to another (shipped from China), you may be subject to pay local taxes and custom duties on said item. The customer is solely responsible for these expenses.
Q5. How many monitors does UM700 support?
A: Hi, UM700 can connect with 3 monitors at the same time.
Q6. If it comes with a wall mount?
A: Hi, yes. UM700 comes with a vesa, you can fix it on the back of the monitor.
Minisforum U700 Mini PC
Regular price $349.90 Sale price $299.00【Intel Core i5】Comes with Intel Core i5-5257U processor,2.70 GHz -3.10 GHz processor frequency,Intel Iris Graphics 6100,U700 Mini PC brings more powerful performance and wonderful experience.
【Upgradeable Memory】U700 has installed DDR3L-1600MT/s 8GB RAM and can be upgraded up to 16GB.It is portable and powerful which can replace the heavy and big Desktop PC easily.
【Flexible Capacity】U700 has installed 256GB Solid State Drives and can expand the storage via 2.5 inch SATA HDD or a TF card(up to 128GB) for your personal needs.
【Three Video Play】U700 is equipped with HDMI,Mini DP and USB-C video play,which enable you to multi-task with ease.Stream 4K video, edit media, work from home, or finish your homework. Get ready for incredible graphics, sound, and performance.
-
Features and Benefits
-
Specifications
-
FAQs & Test Report
Features & Functions for U700 Mini PC
Multiple Application Options
Making the gigantic desktop power in a tiny package, U700 Mini PC is widely used both at home and office, such as monitor, projector, media player and so on.
High Definition 4K Thriple Display
U700 Mini PC offers you high dedinition 4k dual display with big fun when watching video, playing games or making a presentation.
Fanless and Silence Design
Very Silent with great performance, this mini pc adopts energy efficient components and cooling elements, there is no noisy during operating and plays 4K video smoothly.
Ports & Buttons for U700
- 1* Power Button 1* DC in Port
- 3* USB 3.0 Port 1* USB-C Port
- 1* HDMI Port 1* Mini DP Port
- 1* TF Card Slot 1* Headphone Jack
- 1* Power LED 2* RJ45 Gigabit Ethernet
Pakage Included
- 1* U700 MINI PC 1* Power Adapter
- 1* HDMI Cable 1* Mini DP Cable
- 1* Mounting Bracket 1* User Manual
Wall Mount Included for Saving Space
The Wall Mount is included in the package, you could fix it on your back of the TV or monitor, which can save your room and make your desktop tidy and neat.
Minisforum U700 Mini PC
Processor
Intel® Core™ i5-5257U Processor , 2 Cores/4 Threads
(3M Cache, up to 3.10 GHz)
GPU
Intel® Iris® Graphics 6100
Memory
DDR3L 8GB×1 Dual channel (SODIMM Slots×2)
Storag
M.2 2280 128GB SATA SSD
Storage Expansion
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
1×TF Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi，BT4.2
Ethernet
1000Mbps LAN
Video Output
① HDMI 1.4(4K@30Hz)
② Mini DP(4K@60Hz)
③ USB-C Port(4K@60Hz)
Audio Output
HDMI 1.4, MINI DP, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×2, USB 3.0 Port×3, TF Card Slot×1, DC Jack×1, Digital MIC×1
Ports & Buttons
1 * Power Button
1 * DC in Port
3 * USB 3.0 Port
1 * USB-C port(4K@60Hz)
1 * HDMI 1.4 Port(4K@30Hz)
1 * Mini DP Port(4K@60Hz)
2 * RJ45 Gigabit Ethernet
1 * Headphone Jack
1 * TF card slot
1 * Power LED
Power
DC 19V/1.9A (adapter included) , or via USB-C Port
System
Windows 10 Pro
Launch Date
May-20
Product Dimension
136×120×46mm
Package Dimension
210×150×80mm
Net Weight
0.45/KGS
Launch Date
0.92/KGS
Package Cotent
1 * Minisforum U700 Mini PC
1 * Power Adapter
1 * Mini DP Cable
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Q1: Can I play fortnite on this?
A: Yes, the U700 mini pc can play the fortnite.
Game effect reference: https://www.youtube.com/watch?v=JE_jdpfeb70 or https://www.youtube.com/watch?v=3_lF4gSMmU8
Customer Reviews
Minisforum GK41 Mini PC
Regular price $269.00 Sale price $239.00【Intel Celeron J4125】Comes with Intel Celeron J4125 processor,2.00 GHz -2.70 GHz processor frequency,Intel UHD Graphics 600,GK41 Mini PC brings more powerful performance and wonderful experience.
【SPECS】Equipped with LPDDR4 8GB Memory and Windows 10 system, the DDR frequency can be up to 2133 MHz.TDP unlocker and Superb cooling system enhances system performances and can efficiently operate for a long time.
【Flexible Capacity】GK41 has installed 128GB Solid State Drives and can expand the storage via M.2 2280 SATA SSD or a TF card(up to 128GB) for your personal needs.
【HD Dual Screen】GK41 is equipped with HDMI 2.0 and Mini DP video play,which enable you to multi-task with ease.Stream 4K video, edit media, work from home, or finish your homework. Get ready for incredible graphics, sound, and performance.
【Additional Feature】4 x USB 3.0 ports ,2 x Gigabit Ethernet ports,3.5mm Audio Jack and a Digital Mic,which meets the needs of home audio to enjoy life.Besides,it includes mounting bracket and support Linux system.
-
Features and Benefits
-
Specifications
-
FAQs & Test Report
Features & Functions for GK41
Multiple Industrial & Commercial Applications
GK41 Mini PC is a perfect device for multiple industial and commercial applications. It can be used for TV, Prejector, Monitor, Printer and other office equipment via 1 HDMI, 1 Mini DP and 1 USB-C outputs.
High Definition 4K Dual Display
Equipped with HDMI and VGA ports, you could connect two monitors at the same time, double efficiency your work or more fun for your entertainment.
High Efficient & Silent Operation
GK41 Mini PC is low consumption, satety and environment protection. Bring you a silent environment to work or have a meeting.
Ports & Buttons for GK41 Mini PC
- 1* Digital MIC 4* USB 3.0 Ports
- 1* Power Button 1* TF Card Slot
- 1* Mic 1* Headphone Jack
- 1* Power Input 2* Gigabit Ethernet
- 1* HDMI Port 1* Display Port
- 1* Reset Hole
Compact but Powerful DeskMini PC
With small but powerful body, this mini pc can bring you great convenience and make you work or entertain everywhere.
Wall-mounted Bracket Support
With the mount bracket available, the slim GN31 is perfect for use in any business environment, also it saves your rooms. Tips: the wall mount has already been included in the package.
Minisforum GK41 Mini PC
CPU
Intel® Celeron® Processor J4125, 4 Cores/4 Threads
(4M Cache, up to 2.70 GHz)
GPU
Intel® UHD Graphics 600
Memory
LPDDR4 8GB (On Board)
Storag
M.2 2280 128GB SATA SSD
Storage Expansion
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
1×TF Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi, BT4.2
Ethernet
1000Mbps LAN
Video Output
① HDMI 2.0(4K@60Hz)
② DP(4K@60Hz)
Audio Output
HDMI 2.0, DP, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×2, USB 3.0 Port×4, TF Card Slot×1, DC Jack×1, Digital MIC×1，MIC×1
Ports & Buttons
1 * Digital MIC
4 * USB 3.0 Ports
1 * Power Button
1 * TF Card Slot
1 * Microphone Jack
1 * Headphone Jack
1 * Power Input
2 * Gigabit Ethernet
1 * HDMI Port
1 * Display Port
1 * Reset Hole
Power
DC 12V/3A (adapter included)
System
Windows 10 Pro
Launch Date
May-20
Product Dimension
125×113×30mm
Package Dimension
210×147×54mm
Net Weight
0.26/KGS
Launch Date
0.75/KGS
Package Cotent
1 * Minisforum GK41 Mini PC
1 * Power Adapter
1 * DP Cable
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Q1: Can this be used for Pf sense Firewall?
A: Yes it can be used for the Pf sense Firewall.
Q2: Does bios have restored power after ac power loss?
A: Yes it has a function of auto power on
Q3: Two questions: 1) Can this machine stream Netflix at 4K? 2) Is the included hdmi cable good enough for 4k@60hz?
A: Yes it is not a problem for streaming Netflix at 4K and yes the HDMI supports 4K@60hz.
Q4: Does the hdmi also send sound, or do i need to connect the sound separately?
A: HDMI has audio + video transmission, and the connected monitor needs to have speakers then it can have sound.
Q5. Will I need to pay custom duties or taxes on my orders?
A: Items shipped from all our warehouses are not subject to export taxes. However, if you are shipping an item from one county to another (shipped from China), you may be subject to pay local taxes and custom duties on said item. The customer is solely responsible for these expenses.
Customer Reviews
Minisforum N40 Mini PC
Regular price $169.90 Sale price $149.00【Ultra 4K@60Hz Display】Equipped with Intel Celeron Gemini Lake N4000/N4020 Processor(up to 2.6GHz/2.8GHz), with Intel UHD Graphics 600, the resolution up to 4096*2160@60Hz and able to play 4K video smoothly.
【Multiple Intelligent Features】supports S5 RTC Wake Settings, Auto Power On, Wake On Lan, PXE Boot etc. Just needs you to set it on the BIOS whenever you want, it will serve you as your request, which is really intelligent.
【Fanless & Silent Design】adopting energy-efficient components and cooling elements, no noise during operating. It offers excellent performance for Internet and Office applications, Media Player, Monitor, Projector and TV.
【Expandable SSD】Powered by the LPDDR4 4GB RAM + 64GB eMMC, extended by DIY SSD + 128GB SD card. Ensure smooth navigation, responsive work processes and comfortable handling of applications and files.
-
Features and Benefits
-
Specifications
-
FAQs & Test Report
Features & Functions for N40 Mini PC
Multiple Application Options
N40 Mini PC is a ideal device for industrial and commercial ativities. It's suitable for monitor, projector, TV, printer and other office equipment.
High Efficient & Silent Design
N40 Mini PC is low consumption, satety and environment protection. Bring you a silent environment to work or have a meeting.
High Definition 4K Display
With high definition 4K dual display, N40 Mini PC offers you the most clearest and fluent experience. Have big fun while playing games with friends and family.
Large Capacity & Extended Storage
This N40 Mini PC can be upgraded to a higher storage to ensure you have enough storage to use.
Ports & Buttons for N40
- 1* Power Input 1* HDMI Port
- 1* LAN Port 1* Headphone Jack
- 1* Reset Hole 1* VGA Port
- 1* SD Card Slot 1* Power Button
- 3* USB 3.0
Wall Mount Support
With the wall-mount bracket available, the slim N40 is perfect for use in any business environment, also it saves your rooms. Tips: the wall mount has already been included in the package.
Minisforum N40 Mini PC
CPU
Intel® Celeron® Processor N4000 , 2 Cores/2 Threads (4M Cache, up to 2.60 GHz)
GPU
Intel® UHD Graphics 600
Memory
LPDDR4 4GB (On Board)
Storag
eMMC 64GB (On Board)
Storage Expansion
1×M.2 2242 SATA SSD Slot (up to 1TB , SATA 3.0 6.0Gb/s)
1×SD Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi，BT4.2 / BT5.0
Ethernet
1000Mbps LAN
Video Output
① HDMI 2.0(4K@60Hz)
② VGA Type Port
Audio Output
HDMI 2.0 , 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×1，USB 3.0 Port×3 , SD Card Slot×1 , DC Jack×1
Ports & Buttons
1 * Power Input
1 * HDMI Port
1 * LAN Port
1 * Headphone Jack
1 * Reset Hole
1 * VGA Port
1 * SD Card Slot
1 * Power Button
3 * USB 3.0
Power
DC 12V/1.5A (adapter included)
System
Windows 10 Pro
Launch Date
December-19
Product Dimension
120×120×27mm
Package Dimension
205×130×60mm
Net Weight
0.25/KGS
Launch Date
0.60/KGS
Package Cotent
1 * Minisforum N40 Mini PC
1 * Power Adapter
1 * Mini DP Cable
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Q1: Will this let me run autocad?
A: Yes, it will.
Q2: What's the power source?
A: The power management of N40 is Adapter DC 12V 1.5A (100-240V,50/60Hz) included.
Q3: Can Ubuntu be installed?
A: Yes, it can support to install the Ubuntu. It is preinstalled with the windows 10 pro so you need to install the ubuntu by yourself. If you need any technical support, please contact us.
Q4: Is it plug and play? Is windows already installed and a license in place, or do I need to purchase the license?
A: It comes with Windows preinstalled and activated. When you turn it on you set yourself up as a new user, or you can enter your existing Windows user info if you already have it. You don't have to pay extra for a license.
Q5: Does this come with a ssd drive? What capacity?
A: Yes, it comes with a 64GB SSD system drive. So it's fully functional right out of the box. You can expand the capacity with the SD Card or M.2 2242 NGFF SSD port if you need additional storage space.
Q6: Can this play hd video for digital signage smoothly and reliably all day off usb memory chip and google drive to update?
A: Yes, it is not a problem to play the hd video all day. Do you need to turn on the function of auto power on?
How to turn on "Auto Power On" : Restart, press DEL repeatedly to nter BIOS-> BOOT-> Auto Power On-> Enable-> press F4 Save and Exit.
Q7: I see it comes with Windows 10 pre-installed, but do I also need to purchase a separate license key? Or is it truly ready to go right out of the box?
A: You don't need to purchase a separate license key.The windows 10 system has been activated which is written to the BIOS.Therefore it won't go right out of the box as well.
Q8: Does this mini-PC have built-in speaker?
A: Sorry that this mini pc has no bulit-in speaker, it has a microphone jack, you could connect the speaker via this jack.
Q9: Will bluetooth headset microphone work?
A: Yes, the product built in BT4.2 or BT5.0, so it will work with your bluetooth headset microphone.
Q10: Is this powerful enough to run Zoom conferencing?
A: Yes, I've used Zoom many times on this PC. It's not super powerful but it gets the job done. Well with the purchase.
Q11. Will I need to pay custom duties or taxes on my orders?
A: Items shipped from all our warehouses are not subject to export taxes. However, if you are shipping an item from one county to another (shipped from China), you may be subject to pay local taxes and custom duties on said item. The customer is solely responsible for these expenses.
Customer Reviews
Minisforum Z83-F Mini PC
Regular price $139.00【Great Processor and OS】: This small mini pc equipped with advanced processor Intel Atom X5-Z8350 and Windows 10 pre-installed, which offers an excellent performance of Internet and Office applications, Media player, Monitor, Projector and TV. An ideal mini pc for users to utilize apps, stream video contents etc.
【Fanless and Silence Design】: Very Silent with great performance, this mini pc adopts energy efficient components and cooling elements, there is no noisy during operating and plays 4K video smoothly.
【Large Capacity】: 4GB RAM+64GB eMMC+128GB SD extended capacity(the SD card didn’t include), Gigabit Ethernet LAN 1000M, Dual Band WiFi, Dual Screen support to ensure smooth navigation, responsive work processes and comfortable handling of apps and files.
-
Features
-
Specifications
-
FAQs
Unboxing for Z83-F Fanless Mini PC
Features & Functions for UM300
Multiple Application Options
This DeskMini PC offers a large range of applications, such as TV, NAS, VGA, monitoring equipment, projector and other office equipment; also it supports different kinds of apps and media player.
HDMI & VGA Dual Displays
With dual connection of HDMI and VGA, it makes possible to connect two monitors at the same time, duoble efficiency for daily work.
Inseparable from Your Life
This DeskMini PC can be widely used for Home Theater, Office Work, Meeting, Education, Projector Monitoring, Host, Printer, Media Equipment, Digital Signboard etc.
Ports & Buttons for Z83-F
- 1* HDMI Port
- 1* VGA Port
- 1* USB 3.0 Port
- 2* USB 2.0 Ports
- 1* Ethernet Port
- 1* Headphone Microphone Jack
- 1* SD Card Slot
- 1* Power Source Port
Fanless & Silent Design
Very Silent DeskMini PC with great performance, this mini pc adopts energy efficient components and cooling elements, there is no noisy during operating and plays 4K video smoothly.
Mini Size with Powerful Perfermance
Portable but powerful performance. Where there is a Z83-F, there is a workplace. Offering you a great convenience in daily life and work.
Minisforum Z83-F Mini PC
Processor
Intel Atom® x5-Z8350 Processor , 4 Cores/4 Threads
(2M Cache, up to 1.92 GHz)
GPU
Intel® HD Graphics 400
Memory
DDR3 4GB (On Board)
Storag
eMMC 64GB (On Board)
Storage Expansion
1×SD Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi，BT4.1
Ethernet
1000Mbps LAN
Video Output
① HDMI Type Port
② VGA Type Port
Audio Output
HDMI, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×1, USB 3.0 Port×1, USB 2.0 Port×2, SD Card Slot×1, DC Jack×1
Ports & Buttons
1 * HDMI Port
1 * VGA Port
1 * USB 3.0 Port
2 * USB 2.0 Ports
1 * Ethernet Port
1 * Headphone Microphone Jack
1 * SD Card Slot
1 * Power Source Port
Power
DC 12V/1.5A (adapter included)
System
Windows 10 Pro
Launch Date
December-17
Product Dimension
120×120×27mm
Package Dimension
205×130×60mm
Net Weight
0.25/KGS
Launch Date
0.6/KGS
Package Cotent
1 * Minisforum Z83-F Mini PC
1 * Power Adapter
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Q1: I saw people mentioning SSD. Does this have a ssd? Is there space for an ssd inside?
A: There's no space for SSD, but there's a slot for SD card to increase space for memory, what you need to do is to buy a card.
Q2: Can I install Windows 10 Pro 32 bit on this machine?
A: Sorry that the product has been pre-installed the Windows 10 Pro 64 bit, it doesn't support 32 bits.
Q3: What key do you press to get into the bios/select different boot device?
A: Please press the Delete key to get into the BIOS.
Q4: Does Z83-F Mini support power on after power fail?
A: Yes, the Z83-F Mini PC supports Power On after Powr Failure.
Q5: What is the email and/or phone number for support on this?
A: You could also send email to "nora@minisforum.com", we will reply you within 24 hours, thanks.
Q6: Is ram expandable to 8GB?
A: Sorry that the RAM of Z83-F can't be upgraded, you could refer to our U500-H, which can upgrade the RAM.
Q7: Where can I buy replacements for the power supply?
A: It comes with a common format 12v 2A adapter, so you could buy one from any number of places.
For example: https://www.amazon.com/COOLM-Adapter-100-240V-Transformer-Charger/dp/B07D5B5Q28 or
https://www.amazon.com/ZYAMY-Adapter-110-250V-Converter-Security/dp/B076B9RDN6
Q8: Does this have display port 1.2?
A: No. This mini computer has a HDMI and a VGA port. I think you would need a active adapter from HDMI to Display Port to make that work. (most adapters you see are display port to hdmi which is easier but wont work for you)
Q9: Can I install a 256g sd card?
A: I'm afraid it only recognizes up to 128GB only. An alternative could also be external usb drive as it supports USB 3.0
Q10: Does it include the wall mount bracket?
A: Yes, the wall mount bracket is included, thanks.
Q11: How do you upgrade the storage space? I do not see any slot for the Emmc upgrade.
A: Sorry that the eMMC of the Z83-F can't be upgraded, you could enlarge the memory via SD card slot. But our GN31, GN41 and U500 Mini PC support upgrade the storage by installing SSD and HDD, thanks.
Customer Reviews
Minisforum Z83-W Mini PC
Regular price $109.00【Excellent Processor and OS】: equipped with Intel Atom X5-Z8350 and Windows 10 Pro pre-installed, bringing excellent experience of the Internet and Office applications, Media player, Monitor, Projector and TV.
【Fanless and Silence design】: Very Silent with great performance, this mini pc adopts energy-efficient components and cooling elements, there is no noise during operating and plays 4K video smoothly. An ideal mini pc for home office, Internet surfing, watching movies, or simply browsing the web.
【Large Capacity】: Mini Desktop Computer is 2GB RAM+32GB eMMC+128GB SD extended,Gigabit Ethernet LAN 1000M, Dual Band WiFi, Dual Screen support to ensure smooth navigation, responsive work processes and comfortable handling of apps and files. It’s the base operating frequency 1.44 GHz/s rising to a 1.92 GHz in burst mode.
-
Features
-
Specifications
-
FAQs
Features & Functions for Z83-W
Multiple Applications Support
Z83-W Mini PC is a wisdom idea for multiple commercial applications. It can be used for Prejector, TV, Minitor, Monitor Equipment, Printer etc.
Two Monitors Support
With dual connection of HDMI and VGA, it makes possible to connect two monitors at the same time, duoble efficiency for daily work.
Inseparable from Your Life
This DeskMini PC can be widely used for Home Theater, Office Work, Meeting, Education, Projector Monitoring, Host, Printer, Media Equipment, Digital Signboard etc.
Ports & Buttons for Z83-W
- 1* HDMI Port
- 1* VGA Port
- 1* USB 3.0 Port
- 2* USB 2.0 Ports
- 1* RJ45 (1000Mbps Network Connection)
- 1* Headphone Microphone Jack
- 1* SD Card Slot
- 1* DC in Port
Fanless & Silent Design
Very Silent with great performance, this mini pc adopts energy efficient components and cooling elements, there is no noisy during operating and plays 4K video smoothly.
Wall Mount include for Saving Room
The Wall Mount is included in the package, you could fix it on your back of the monitor, which can save your room and make your desktop tidy and neat.
Minisforum Z83-W Mini PC
Processor
Intel Atom® x5-Z8350 Processor , 4 Cores/4 Threads
(2M Cache, up to 1.92 GHz)
GPU
Intel® HD Graphics 400
Memory
DDR3 2GB (On Board)
Storag
eMMC 32GB (On Board)
Storage Expansion
1×SD Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi，BT4.1
Ethernet
1000Mbps LAN
Video Output
① HDMI Type Port
② VGA Type Port
Audio Output
HDMI, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×1, USB 3.0 Port×1, USB 2.0 Port×2, SD Card Slot×1, DC Jack×1
Ports & Buttons
1 * HDMI Port
1 * VGA Port
1 * USB 3.0 Port
2 * USB 2.0 Ports
1 * RJ45 (1000Mbps Network Connection)
1 * Headphone Microphone Jack
1 * SD Card Slot
1 * DC in Port
Power
DC 12V/1.5A (adapter included)
System
Windows 10 Pro
Launch Date
December-17
Product Dimension
120×120×27mm
Package Dimension
205×130×60mm
Net Weight
0.20/KGS
Launch Date
0.45/KGS
Package Cotent
1 * Minisforum Z83-W Mini PC
1 * Power Adapter
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Q1: Where would one go to get support?
A: You can email us at minisforumtech@gmail.com
Q2: Can the memory be upgraded?
A: Sorry that the memory can't be upgraded on this device, the U500-H, U550 and U800 Mini PCs in our store can upgrade the memory.
Q3: What about graphics card for this?
A: It‘s Intel HD Graphics 400, thanks.
Q4: What version of windows 10 is Pre-installed?
A: It has pre-installed Windows 10 Pro.
Q5. Will I need to pay custom duties or taxes on my orders?
A: Items shipped from all our warehouses are not subject to export taxes. However, if you are shipping an item from one county to another (shipped from China), you may be subject to pay local taxes and custom duties on said item. The customer is solely responsible for these expenses.
Customer Reviews
Minisforum U500-H Mini PC
Regular price $299.90 Sale price $259.00【Advanced Processor with Windows 10 Pro】This small U500-H mini pc equipped with advanced processor Intel Core i3-5005U and Windows 10 Pro pre-installed, which offers an excellent performance of Internet and Office applications, Media player, Monitor, Projector and TV. An ideal Mini PC for users to play games, utilize apps, stream video contents, etc.
【Large Capacity】Installed 8GB RAM + 128GB SSD+ Micro SD card up to 128GB(not included)+ Upgrade RAM(up to 16GB)+DIY NGFF M.2 2280 SSD(up to 1TB)+DIY 2.5”HDD(up to 2TB)
【Triple Screen Output】Gigabit Ethernet LAN 1000M, Dual Band WiFi, Triple Screen support to ensure smooth navigation, responsive work processes and comfortable handling of apps and files.
【Features】
1) supports Linux and Chromium System, Wake On Lan and PXE boot. Support extend RAM, SSD and HDD.
2) Making the gigantic desktop power in a tiny package, the Mini PC full of all traditional desktop’s features.
3) Powered by the Intel i3-5005u processor, get avoid of cluttering and compromising performance.
4) Compact, Light, Quiet and Powerful.
-
Features and Benefits
-
Specifications
-
FAQs & Test Report
Features & Functions for U500-H Mini PC
Multiple Applications Support
U500-H Mini PC is a wisdom idea for multiple commercial applications. It can be used for Prejector, TV, Minitor, Monitor Equipment, Printer etc.
Perfect Home Video Player Mini PC
Equipped with HDMI, Mini DP and USB-C, you could connect three monitors at the same time, more efficiency, fluency and definition your work or more fun for your entertainment.
Two Gigabit Ethernet Support
Two built-in Gigabit Ethernet makes transfer and download more faster. Easy to use and much more efficient.
Small but Powerful DeskMini PC
U500-H DeskMini PC is small but powerful -- easy to carry with, easy to pocket. Make you work or entertainment everywhere you want.
Ports & Buttons for U500-H:
- 1* USB-C (PD + 4K@60Hz Video + Dual)
- 1*HDMI 1.4 Port (4K@30Hz)
- 1* Mini DP Port (4K@60Hz)
- 1* DC 12V/3A Input
- 1* Headphone Jack
- 2* Gigabit Ethernet
- 1* Power Button
- 1* Reset Button
- 3* USB 3.0
Wall Mount include for Saving Space
The Wall Mount is included in the package, you could fix it on your back of the TV or monitor, which can save your room and make your desktop tidy and neat.
Minisforum U500-H Mini PC
Processor
Intel® Core™ i3-5005U Processor , 2 Cores/4 Threads
(3M Cache, 2.00 GHz)
GPU
Intel® HD Graphics 5500
Memory
DDR3L 8GB×1 Dual channel (SODIMM Slots×2)
Storag
M.2 2280 128GB SATA SSD
Storage Expansion
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
1×TF Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi，BT4.2
Ethernet
1000Mbps LAN
Video Output
① HDMI 1.4 (4K@30Hz)
② Mini DP(4K@60Hz)
③ USB-C Port(4K@60Hz)
Audio Output
HDMI 1.4, MINI DP, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×2, USB 3.0 Port×3, TF Card Slot×1, DC Jack×1, Digital MIC×1
Ports & Buttons
1 * USB-C (PD + 4K@60Hz Video + Dual)
1 * HDMI 1.4 Port (4K@30Hz)
1 * Mini DP Port (4K@60Hz)
1 * DC 12V/3A Input
1 * Headphone Jack
2 * Gigabit Ethernet
1 * Power Button
1 * Reset Button
3 * USB 3.0
Power
DC 12V/3A (adapter included) , or via USB-C Port
System
Windows 10 Pro
Launch Date
July-19
Product Dimension
136×120×46mm
Package Dimension
210×150×80mm
Net Weight
0.38/KGS
Launch Date
0.90/KGS
Package Cotent
1 * Minisforum U500-H Mini PC
1 * Power Adapter
1 * Mini DP Cable
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Q1: Can I hook this mini pc up to 2 displays wo using the VGA port?
A: Yes, you can connect 2 displays via VGA and HDIM ports.
Q2: Does this support debian linux?
A: Yes, this mini pc supports Linux system.
Q3: What are the lan chipsets on the i3-5005u mini pc? intel or realtek?
A: The lan chipsets on the i3-5005U mini pc is REALTEK.
Q4: Can it be working on wireless keybord?
A: Yes with usb adapter.
Q5: Is this compatible with crucial mx500? ct250mx500ssd4 is the model number. It gets stuck on bios.
A: U500-H not support 2.5-inch SSD(Solid State Drives） , only support 2.5-inch ( Hard Disk Drive)
Q6: Please clarify: how much ram and hdd space is provided out of the box?
A: This mini pc equipped with 8GB RAM and 128GB SSD.If the product has any problems, you can communicate with us via e-mail: minisforumtech@gmail.com, We will do everything possible to resolve your problem.
Q7: Is this single channel ram or does it have 2 ram slots?
A: It has two ram slots, thanks.
Q8: Can I connect to internet with WiFi, then use ethernet ports to supply lan access to other devices?
A: Yes, you could connect to internet with wifi, than use the ethernet port to supply lan access to other devices, thanks.
Q9: How long can this computer be left on?
A: I have mine hosting an application that runs 24/7. Has been running continuously for many months except for occasional reboots for Windows updates.
Q10: Can the U500-H be connected to a pair of monitors that are both HDMI?
A: The U500-H Mini PC has one HDMI, one Mini DP and one USB-C ports, you could use a USB-C to HDMI port to make it connect to a pair of monitors, it doesn't support Mini DP to HDMI adapter at present, it supports Mini DP to VGA adapter.
Q11: What is the key in order to bring up the boot menu?
A: You could press F7 constantly after starting the mini pc or press "Delete" to enter into the BIOS and choose boot menu.
Q12. Will I need to pay custom duties or taxes on my orders?
A: Items shipped from all our warehouses are not subject to export taxes. However, if you are shipping an item from one county to another (shipped from China), you may be subject to pay local taxes and custom duties on said item. The customer is solely responsible for these expenses.
Customer Reviews
Minisforum EliteMini H31
Regular price $399.00 Sale price $369.00【Excellent Processor and OS】: equipped with Intel® Core™ i3-9100 Processor，4 Cores/4 Threads and Windows 10 Home, bringing excellent experience of the Internet and office applications, Media player, Monitor, Projector and TV.
【Fanless and Silence design】: Very Silent with great performance, this mini pc adopts energy-efficient components and cooling elements, there is no noise during operating and plays 4K video smoothly. An ideal mini pc for home office, Internet surfing, watching movies, or simply browsing the web.
【Large Capacity】: Mini Desktop Computer is 16GB RAM (SODIMM Slots×2)+256GB SSD+1TB HDD extended, Gigabit Ethernet LAN, Dual Band WiFi, Dual Screen support to ensure smooth navigation, responsive work processes and comfortable handling of apps and files. It’s the base operating frequency 3.6 GHz/s rising to a 4.2 GHz in burst mode.
-
Features and Benefits
-
Specifications
-
FAQs
Features & Functions for H31
Multiple Application Options
H31 Mini PC is an ideal helper for multiple industrial and commercial applications.
It can be used for Prejector, TV, Minitor, Printer, other office equipment etc.
High Definition 4k Dual Display
1x HDMI and 1xMini DP for 4K@30Hz output, Gigabit Ethernet LAN, Dual Band WiFi to ensure smooth navigation, responsive work processes and comfortable handling of apps and files.
Fanless & Silence Design
H31 Mini PC is low consumption, satety and environment protection. Bring you a silent environment to work or have a meeting.
Ports & Buttons for H31 Mini PC
- 1* Power Input 1* HDMI Port
- 1* Mini Display Port 1* LAN Port
- 2* USB 3.0 Port 1* Kensington Lock
- 1* TF Card Slot 1* Audio Output
- 1* MIC Input 1* HP Output
- 1* Microphone Jack 1* Reset Hole
- 1* Power Button
Larger Capacity & Expanded Storage
H31 Mini PC is 16GB RAM (SODIMM Slots×2)+256GB SSD+1TB HDD extended, Gigabit Ethernet LAN, Dual Band WiFi, Dual Screen support to ensure smooth navigation, responsive work processes and comfortable handling of apps and files. It’s the base operating frequency 3.6 GHz/s rising to a 4.2 GHz in burst mode.
Wall Mount Support
The Wall Mount is included in the package, you could fix it on the back of the monitor or TV, which can save your room and make your desktop tidy and neat.
MINISFORUM EliteMini H31
CPU
Intel® Core™ i3-9100 Processor，4 Cores/4 Threads
(6M Cache, up to 4.20 GHz)
GPU
Intel® UHD Graphics 630
Memory
DDR4 8GB×2 Dual channel (SODIMM Slots×2)
Storag
M.2 2280 256GB PCIe SSD
Storage Expansion
1×M.2 2242 SATA SSD Slot (up to 1TB , SATA 3.0 6.0Gb/s)
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
1×TF Card Slot (up to128GB)
Wireless Connectivity
M.2 2230 WIFI Support (Intel® WIFI6 AX200，BT5.1 pre-install)
Video Output
① HDMI(4K@30Hz)
② Mini DisplayPort(4K@60Hz)
Audio Output
HDMI, Mini DisplayPort, 3.5mm Audio Jack, LINE IN, HP OUT
Peripherals Interface
RJ45 Gigabit Ethernet Port×1, USB 3.0 Port×4, TF Card Slot×1, MIC×1
Ports & Buttons
1 * Power Input
1 * HDMI Port
1 * Mini Display Port
1 * LAN Port
2 * USB 3.0 Port
1 * Kensington Lock
1 * TF Card Slot
1 * Audio Output
1 * MIC Input
1 * HP Output
1 * Microphone Jack
1 * Reset Hole
1 * Power Button
Power
DC 19V/6.3A (adapter included)
System
Windows 10 Home
Launch Date
July-20
Product Dimension
154×153×62mm
Package Dimension
192×192×160mm
Net Weight
1.08/KGS
Launch Date
2.10/KGS
Package Cotent
1 * MINISFORUM EliteMini H31
1 * Power Adapter
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Q1. Will I need to pay custom duties or taxes on my orders?
A: Items shipped from all our warehouses are not subject to export taxes. However, if you are shipping an item from one county to another (shipped from China), you may be subject to pay local taxes and custom duties on said item. The customer is solely responsible for these expenses.
Kodlix GD41 Mini PC
Regular price $279.00 Sale price $249.00【Ultra 4K@60Hz Display】: This GD41 micro pc comes with Intel Celeron Gemini Lake N4100 / N4120 Processor(up to 2.4Gz), with Intel UHD Graphics 600, the resolution up to 4096*2160@60Hz and able to play 4K video smoothly.
【Fanless & Multiple Intelligent Features】:It adopts fanless design,energy efficient components and cooling elements, no noise during operating. It supports S5 RTC Wake Settings, Auto Power On, Wake On Lan, PXE Boot etc. Just need you to set it on the BIOS whenever you want, it will serve you as your request.
【Triple Monitors Support】: 1x HDMI 2.0a, 1xMini DP, 1xUSB-C for 4K@60Hz output, all of the outputs support 4K@60Hz display. Gigabit Ethernet LAN 1000M, Dual Band WiFi to ensure smooth navigation, responsive work processes and comfortable handling of apps and files.
【Extensible Capacity】: Powered by the DDR4 8GB RAM + 128GB NVMe SSD, extended by DIY SSD/HDD + 128GB SD card. RAM can be upgraded to 32GB. DIY NGFF 2280 SSD and 2.5’’ SATA HDD up to 2TB.
【Package & Warranty】: 1x GD41 Mini PC; 1x Mounting Bracket; 1x HDMI cable; 1x Mini DP cable; 1x US Power adapter(12V/3A); 1x Manual. 1 year warranty, 1 month free return, get after sell service support within 24 hours.
-
Features and Benefits
-
N4100 SPEC
-
N4120 SPEC
-
FAQs
Features & Functions for GD41
Multiple Interfaces and Activities
This Mini PC is a perfect device for many industrial and commercial applications. It can be connected with monitor, projector, TV, printer and other office equitments.
High Definition 4K Triple Display
Triple display connection makes your work more efficient and more covenient. 1*DP, 1*HDMI and 1*USB-C support 4k HD display output, bring you great visual enjoymentn. Also this Mini PC is low consumption and environmental.
Fanless and Silent Design
This GD41 Mini PC adopts energy efficient components and cooling elements, many ventilation holes for heat dissipatioin, fanless for 0 noise during operating, offers a great working environment.
Ports & Buttons for GD41
- 1* DC Port 1* Mini DP
- 1* HDMI Port 1* Power Button
- 1* Microphone Jack 1* TF Card Slot
- 1* Kensington Lock 1* USB-C Port
- 1* Reset Hole 1* Headphone Jack
- 2* Gigabit Ethernet Port 3* USB 3.0
Large Capacity & Extended Storage
Powered by the DDR4 8GB RAM + 128GB NVMe SSD, extended by DIY SSD/HDD + 128GB SD card. RAM can be upgraded to 32GB. DIY NGFF 2280 SSD and 2.5’’ SATA HDD up to 2TB.
Wall Mount Included for Saving Space
The Wall Mount is already included in the package, you could fix it on your back of the TV or monitor, which can save your room and make your desktop tidy and neat.
Kodlix GD41 (N4100) Mini PC
CPU
Intel® Celeron® Processor N4100, 4 Cores/4 Threads
(4M Cache , up to 2.40 GHz)
GPU
Intel® UHD Graphics 600
Memory
DDR4 8GB Dual channel (SODIMM Slots×2)
Storag
M.2 2242 128GB PCIe SSD
Storage Expansion
1×M.2 2280 SATA SSD Slot (up to 1TB , SATA 3.0 6.0Gb/s)
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
1×TF Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi，BT5.0
Ethernet
1000Mbps LAN
Video Output
① HDMI 2.0 (4K@60Hz)
② Mini DP (4K@60Hz)
③ USB-C Port (4K@60Hz)
Audio Output
HDMI 2.0, Mini DP, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×2, USB 3.0 Port×3, TF Card Slot×1, DC Jack×1, Digital MIC×1
Ports & Buttons
1 * HDMI Port(4K@60Hz)
1 * Mini DP Portt(4K@60Hz)
1 * USB-C(4K@60Hz)
3 * USB 3.0 Port
2 * RJ45 Port
1 * Headphone&Microphone Jack
1 * SD Card slot
1 * DC Port
1* Power Button
1 * Reset jack
Power
DC 12V/3A (adapter included)
System
Windows 10 Pro
Launch Date
March-20
Product Dimension
136×120×46mm
Package Dimension
210×150×80mm
Net Weight
0.45/KGS
Launch Date
0.95/KGS
Package Cotent
1 * Mini PC
1 * Power Adapter DC12V/3A (100-240V,50/60Hz)
1 * HDMI Cable
1 * Mini DP Cable
1 * Mounting Bracket
1 * User Manual
Kodlix GD41 (N4100) Mini PC
CPU
Intel® Celeron® Processor N4120, 4 Cores/4 Threads
(4M Cache, up to 2.60 GHz)
GPU
Intel® UHD Graphics 600
Memory
DDR4 8GB Dual channel (SODIMM Slots×2)
Storag
M.2 2242 128GB PCIe SSD
Storage Expansion
1×M.2 2280 SATA SSD Slot (up to 1TB , SATA 3.0 6.0Gb/s)
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
1×TF Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi，BT5.0
Ethernet
1000Mbps LAN
Video Output
① HDMI 2.0 (4K@60Hz)
② Mini DP (4K@60Hz)
③ USB-C Port (4K@60Hz)
Audio Output
HDMI 2.0, Mini DP, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×2, USB 3.0 Port×3, TF Card Slot×1, DC Jack×1, Digital MIC×1
Ports & Buttons
1 * HDMI Port(4K@60Hz)
1 * Mini DP Portt(4K@60Hz)
1 * USB-C(4K@60Hz)
3 * USB 3.0 Port
2 * RJ45 Port
1 * Headphone&Microphone Jack
1 * SD Card slot
1 * DC Port
1* Power Button
1 * Reset jack
Power
DC 12V/3A (adapter included)
System
Windows 10 Pro
Launch Date
March-20
Product Dimension
136×120×46mm
Package Dimension
210×150×80mm
Net Weight
0.45/KGS
Launch Date
0.95/KGS
Package Cotent
1 * Kodlix GD41 (N4100) Mini PC
1 * Power Adapter DC12V/3A (100-240V,50/60Hz)
1 * HDMI Cable
1 * Mini DP Cable
1 * Mounting Bracket
1 * User Manual
Minisforum N33 Mini PC
Regular price $149.00 Sale price $119.00【Better Processor】N33 Mini PC pre-installed with Windows 10 Pro, support Ubuntu& Linux, Intel Celeron Processor N3350 up to 2.4 GHz. And loaded with upgraded LPDDR4 4GB + eMMC 64GB. Thanks to the new technology of LPDDR4, power consumption is greatly reduced at a constant frequency.
【Large Capacity Expansion】N33 4GB RAM+64GB eMMC mini-computer supports DIY expand the storage with a micro128GB SD card, 1 TB 2242 SATA SSD(SD card/ SSD is not included), 2TB mobile hard disk box via USB3.0 interface.
【Dual WIFI】N33 mini PC supports 2.4GHz+ 5.8GHz dual Band Wi-Fi and 1000Mbps LAN, so whether it’s uploading or downloading, the speed is very fast and smooth. Bluetooth 4.2 allows you to connect to a variety of wireless devices at will, and this computer supports S5 RTC Wake Settings, Auto Power On, Wake On Lan, PXE Boot etc. You can set it on the BIOS, very convenient to use.
【Dual Display & Intel HD Graphics】Enjoy smooth 4k HD video at home and deliver a great TV experience with true-to-life picture quality. With this mini-computer, you can enjoy various entertainment with your family. HDMI / VGA ports support easily connect two monitors, greatly improving your productivity.
【Why we recommend N33 to you】Our group has been dedicated to the production of mini PC for many years, N33 is a NEW VERSION mini-computer we developed, it‘s good value for money. We offer LIFETIME technical support, 24 months of warranty and uninterrupted service online. Only products from KODLIX Store are officially authorized genuine products, and the purchase of pirated products from other stores cannot be supported by the official website.
NOTES: The adapter has been certified by PSE while the Mini PC has been certified by GITEKI. Picture as follow:
-
Features
-
Specifications
-
FAQs
Features & Functions for N33 Mini PC
Multiple Application Options
Targeting the use of small business, industrial automatic control, home theater and living room. It’s very low power consumption and a great savings on the electric bill.
HDMI & VGA Support Dual Displays
Dual screen display makes your work more efficient. HDMI and VGA port support 4k HD display output, bring you great visual enjoyment.
Dual WiFi & BT4.2 Connection
Dual brand WiFi and built-in Gigabit ethernet make the transmission speed faster and the signal more stable.
Ports & Buttons for N33:
- 1* DC 12V Adapter
- 1* USB 3.0
- 1* USB 3.0 for the mouse/keyboard
- 1* Connect HDMI to TV
- 1* Connect the Ethernet
- 1* Headphone Jack
- 1* VGA Port
- 1* SD Card Slot
Small & Portable for DeskMini PC
Portable but powerful performance. Where there is a N33, there is a workplace. Offering you a great convenience in daily life and work. Easy to carry and convenient to use.
Wall Mount Support
N33 Mini PC is wall-mount support, which is more space-efficient. Tips: the wall mount is included in the package, which can be fixed on the back of the TV or monitor.
Minisforum N33 Mini PC
Processor
Intel® Celeron® Processor N3350E , 2 Cores/2 Threads
(2M Cache, up to 2.4 GHz)
GPU
Intel® HD Graphics 500
Memory
LPDDR4 4GB (On Board)
Storag
eMMC 64GB (On Board)
Storage Expansion
1×M.2 2242 SATA SSD Slot (up to 1TB , SATA 3.0 6.0Gb/s)
1×SD Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi, BT4.2
Ethernet
1000Mbps LAN
Video Output
① HDMI Type Port
② VGA Type Port
Audio Output
HDMI, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×1，USB 3.0 Port×3, SD Card Slot×1, DC Jack×1
Ports & Buttons
1 * DC 12V Adapter
1 * USB 3.0
1 * USB 3.0 for the mouse/keyboard
1 * Connect HDMI to TV
1 * Connect the Ethernet
1 * Headphone Jack
1 * VGA Port
1 * SD Card Slot
Power
DC 12V/2A (adapter included)
System
Windows 10 Pro
Launch Date
April-20
Product Dimension
120×120×27mm
Package Dimension
205×130×60mm
Net Weight
0.25/KGS
Launch Date
0.60/KGS
Package Cotent
1 * Minisforum N33 Mini PC
1 * Power Adapter
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Q1: Does this unit support touch screen?
A: N33 supports VGA and HDMI output, but does not support touch screen.
Q2: Are all types of 128GB micro sd cards supported? Are there some kinds that won't work?
A: To make the computer work better, we recommend that you install an SDHC card.
Q3: Where do I find instructions on how to install a ssd ?
A: The SSD is installed internally. You need to purchase an external USB to SATA enclosure if you own a SATA SSD. This Mini PC doesn't have room for an internal SSD 2.5 inch SATA. You can understand the operation by watching the video https://youtu.be/n5qAgph8mR8 Or PDF http://www.mediafire.com/file/i2zyejk1egiymo4/GN34%25E6%258B%2586%25E6%259C%25BA%25E6%2596%25B9%25E5%25BC%258F%25E5%25AE%2589%25E8%25A3%2585SSD.pdf/file
Q4: Does this unit come with built in wifi or do you need a seperate USB wifi adapter?
A: N33 Mini PC built-in 802.11ac 2.4GHz+ 5.0GHz dual Band Wi-Fi and 1000Mbps LAN, so whether it's uploading or downloading, the speed is very fast and smooth. Bluetooth 4.2 allows you to connect to a variety of wireless devices at will, very convenient to use.
Q5: Does it come with Word, Excel, etc?
A: These software needs to be downloaded by yourself, our machine only pre-installed windows10 system.
Q6: Do the usb 3.0 ports definitely work with a usb 2.0 mouse, keyboard, and printer?
A: Yes, the USB 3.0 ports can work with a USB 2.0 mouse, keyboard and printer.
Q7: Will the n33 run ubuntu server? if yes, will it auto-restart after a power failure?
A: Yes, N33 mini pc can run ubuntu serve. And if you need to set up auto-restart, you can follow the instructions in the link http://bbs.minisforum.com/threads/n33-presentation-and-some-software.1276/
Q8: Can you upgrade the 4gb ddr4 with more memory?
A: This Mini PC can't upgrade the ram, but if you need more capacity expansion, you can DIY expand the storage with a micro128GB SD card, 1 TB 2242 SATA SSD, 2TB mobile hard disk box via USB3.0 interface.
Customer Reviews
Minisforum S40 Mini PC Stick
Regular price $149.00【World’s first PC Stick】Supporting dual 4k display. with Intel Celeron Gemini Lake N4000 Processor(up to 2.6Gz), and inbuilt UHD Graphics 600, the resolution up to 4096 * 2160 @60Hz and able to play 4K video smoothly.
【Multiple Smart Features】RTC Wake Settings, Auto Power On. Just set it up on the BIOS as you need.
【Stick Size While Smooth Experience】Powered by the LPDDR4 4GB RAM + 64GB eMMC, Ensure smooth navigation, responsive work processes and comfortable handling of applications and files.
【Two 4K@60Hz Monitors Support】With HDMI and Mini DP port of 4K@60Hz, bringing excellent performance for Internet and Office applications, Media Player, Monitor, Projector, and TV.
-
Features and Benefits
-
Specifications
-
FAQs & Test Report
CPU Details for S40 Mini PC Stick
With Intel Celeron Gemini Lake N4000 Processor(up to 2.6Gz), and inbuilt UHD Graphics 600, the resolution up to 4096*2160@60Hz and able to play 4K video smoothly.
Multiple Application Options
S40 Mini PC Stick is a perfect device for multiple commercial applications. It can be used for Prejector, TV, Minitor, Monitor Equipment, Printer etc.
Three ways to connect to your monitor:
A: Connect the HDMI Port of Stick PC to display via the display port cable
B: Connect the Mini Display Port of Stick PC to display via the display port cable
C: Connect the HDMI Port of Stick PC to HDMI adapter first, then connect it to display via HDMI cable
Fluent 4K Video Streaming
High definition 4K Dual display allows easy connection for two display via 1 HDMI and 1 Mini DP outputs.
Ports & Buttons for S40
- 1* HDMI Port 1* Mini Display Port
- 1* Power Button 1* TF Card Slot
- 1* USB 3.0 Port 1* Reset Hole
- 1* USB-C Port (power port)
Small but Power Mini PC Stick
S40 Mini PC Stick is small but powerful -- easy to carry with, easy to pocket. It supports two band -- 2.4G+5G dual-band WiFi, making transfer and download more faster.
Minisforum S40 Mini PC
Processor
Intel® Celeron® Processor N4000, 2 Cores/2 Threads
(4M Cache, up to 2.60 GHz)
GPU
Intel® UHD Graphics 600
Memory
LPDDR4 4GB (On Board)
Storag
eMMC 64GB (On Board)
Storage Expansion
1×TF Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi，BT5.0
Video Output
① HDMI 2.0 (4K@60Hz)
② MINI DP (4K@60Hz)
Audio Output
HDMI 2.0, MINI DP
Peripherals Interface
USB 3.0 Port×2, TF Card Slot×1, USB-C (Power Port)×1
Ports & Buttons
1 * HDMI port
1 * Mini display port
1 * Power Button
1 * TF Card Slot
1 * USB 3.0 Port
1 * Reset Hole
1 * USB-C Port (power port)
Power
5V/3A (adapter included)
System
Windows 10 Pro
Launch Date
April-20
Product Dimension
133×46×14mm
Package Dimension
170×83×73mm
Net Weight
0.10/KGS
Launch Date
0.45/KGS
Package Cotent
1 * Minisforum S40 Mini PC
1 * Power Adapter
1 * Mini DP Cable
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Q1: Can I use an external USB stick with this computer stick ?
A: Yes, this intel celeron stick has 2 usb 3.0 ports which can be used for it.
Customer Reviews
Kodlix GK45 Mini PC
Regular price $219.00【Advanced Processor with Windows 10】This small GK45 Mini PC equipped with power Intel Gemini Lake J4105 Processor, it’s Intel UHD Graphics 600, which offers an excellent performance of Internet and Office applications, Media player, Monitor, Projector and TV and support 4K@60Hz display.
【New TDP Unique Unlocker Technology】This micro GK45 featured with a unique unlocker, it can completely unlock the performance of the Gemini Lake J4105 and optimize CPU&GPU’s performance. Under 100% loading(48 hours without interreupted operation), the frequency will not be reduced. This function is more than 80% higher than the limit performance of the same series Mini PC.
【Large On-board and Extensible Storage】Installed LPDDR4 4GB RAM + 128GB NVMe SSD + DIY M.2 2242 NVMe SSD( up to 2TB) + DIY M.2 2280 NGFF SSD(up to 2TB) + DIY 2.5’’ HDD(up to 2TB). The operation system can be installed on NVMe SSD for faster response.
【4K@60Hz Output for Triple Monitors & 2x RJ45 Ports 】This Micro PC featured with three video outputs -- HDMI 2.0, Mini DP and USB-C, all of them support 4K@60Hz. Double gigabit network ports will increase the use of possibility for more households and industrials and ensure smooth navigation, responsive work processes and comfortable handling of apps and files.
-
Features and Benefits
-
Specifications
-
FAQs & Test Report
Features & Functions for GK45
Multiple Application Options
This GK45 Mini PC is a ideal device for industrial and commercial ativities. It's suitable for monitor, projector, TV, printer and other office equipment.
High Definition 4K Dual Display
High definition 4K triple display allows easy connection for up to dual displays via 1 HDMI, 1 Mini DP and 1 USB-C outputs. Make your work more efficient and save your time.
Large Capacity
It's not difficult to upgrage the storage. With SSD and HDD, it can be easily upgraded to a larger capacity.
Tips: the SSD and HDD is not included, and it requires an additional purchase.
Two Gigabit Ethernet
With two Gigabit Ethernet, which will greatly expand its functions. Also make you transfer and download more fluent and quicker.
Ports & Buttons for GK45 Mini PC
- 1* DC Input 1* Mini DP Port
- 1 HDMI Port 1* Reset Button
- 2 Gigabit Ethernet 1* USB-C Port
- 1 Reset Button 1* Microphone
- 3 USB 3.0 Ports 1* Power Button
Wall Mount Included for Saving Space
The Wall Mount is included in the package, you could fix it on your back of the TV or monitor, which can save your room and make your desktop tidy and neat.
Kodlix GN45 Mini PC
Processor
Intel® Celeron® J4105 Processor , 4 Cores/4 Threads
(4M Cache, up to 2.50 GHz)
GPU
Intel® UHD Graphics 600
Memory
LPDDR4 4GB (On Board)
Storag
eMMC 64GB (On Board)
Storage Expansion
1×M.2 2280 SATA SSD Slot (up to 1TB , SATA 3.0 6.0Gb/s)
1×M.2 2242 PCIe SSD Slot (up to 1TB , PCle)
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
1×TF Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi，BT5.0
Ethernet
1000Mbps LAN
Video Output
① HDMI 2.0(4K@60Hz)
② Mini DP(4K@60Hz)
③ USB-C Port(4K@60Hz)
Audio Output
HDMI 2.0, Mini DP, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×2, USB 3.0 Port×3, TF Card Slot×1, DC Jack×1, Digital MIC×1
Ports & Buttons
1 * DC Input
1 * Mini DP Port
1 * HDMI Port
2 * Gigabit Ethernet
1 * USB-C
1 * Reset Button
3 * USB 3.0 Ports
1 * Power Button
1 * Microphone.
Power
DC 12V/3A (adapter included), or via USB-C Port
System
Windows 10 Pro
Launch Date
August-19
Product Dimension
136×120×46mm
Package Dimension
210×150×80mm
Net Weight
0.38/KGS
Launch Date
0.90/KGS
Package Cotent
1 * Kodlix GK45 Mini PC
1 * Power Adapter
1 * Mini DP Cable
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Q1: How to access Bios?
A: Please press the "DELETE" key immediately to enter into the BIOS after power on the computer.
Q2: What kind of hard disk is installed? Emmc or ssd?
A: For the GK45 4+64GB Model, it has been installed the 64GB eMMMC, but you could install the SSD by yourself.
For the GK45 4+128GB Model, it has been installed the 128GB NVMe SSD.
Q3: Can I add more storage? If yes what kind memory can i add?
A: Yes, you could add more storage on this GK45 Mini PC, such as NMVe SSD(up to 2TB), NGFF SSD(up to 2TB), 2.5'' HDD(up to 2TB).
Q4: Does it automatic power on after power failure?
A: Yes, the GK45 Mini PC supports auto power on after power failure.
It needs you to update the EC to has this function: http://bbs.minisforum.com/threads/support-auto-power-on.1259/
Q5: Would it can be work as a tv media player and connected to a nas?
A: Yes, it can be work as a tv media player and connected to a NAS.
Q6: Does the Type-C port support video output?
A: Yes, the GK45's Type-C port supports 4K@60Hz video output.
Q7: Can it be used as a home theater medea player on a 4k @60 hz, plus HD sound (like dolby atmos)?
A: Yes, this GK45 Mini PC can be used as a home theater media player on 4K@60Hz without any problems, the other answer from Jeff is for Z83 model and didn't contact us for solution, he never buy GK45 model.
Q8: Is the kodlix GK45 fanless?
A: Sorry that the GK45 is not fanless, it has a small fan in it, our GD41 Mini PC is fanless.
Q9: What setting do you change for the auto power on function?
A: You could enter into the BIOS to set it.
Q10. Will I need to pay custom duties or taxes on my orders?
A: Items shipped from all our warehouses are not subject to export taxes. However, if you are shipping an item from one county to another (shipped from China), you may be subject to pay local taxes and custom duties on said item. The customer is solely responsible for these expenses.
Customer Reviews
Minisforum GN34 Mini PC
Regular price $179.00【Great Processor and OS】Apolo Lake J3455 and Win 10 Pro pre-installed, offering excellent experience for the Internet and Office applications, Media player, Monitor, Projector and TV. An ideal mini pc for users to play games, utilize apps, stream video contents, etc.
【Large Capacity】8GB RAM+ 64GB eMMC+ 128GB SD extended capacity(SD card not included), DIY M.2 SSD(Max support 2TB), Gigabit Ethernet LAN 1000M, Dual Band WiFi, Dual Screen support to ensure smooth navigation, responsive work processes and comfortable handling of apps and files.
【Dual Monitor Support】Having both HDMI and VGA ports, two monitors can be operated at the same time, boost working efficiency and more fun for amusement.
【Mini Size for Space-saving】Palm-size design with quiet fan. Also, it could be very space-saving with mounting bracket included, perfect for use in any business environment.
-
Features and Benefits
-
Specifications
-
FAQs & Test Report
Featured with sufficient I/O interfaces, the GN34 Mini PC has high-speed data access, plenty of storage, stable low-power processor with powerful Linux system, making it a perfect product for industrial automatic control With the mount bracket available, the slim GN34 is perfect for use in any business environment. The GN34 Mini computer aims at delivering maximum product performance without any performance losses.
Features & Functions for GN34 Mini PC
Multiple Application Options
GN34 Mini PC is a ideal device for multiple industrial and commercial applications. It can be used for TV, Prejector, Minitor, Monitor Equipment, Printer etc.
HDMI & VGA Support Dual Displays
GN34 Mini PC supports two band -- 2.4G+5G dual-band WiFi and built-in Gigabit Ethernet, making transfer and download more faster.
High Efficient & Silent Design
GN34 Mini PC is low comsumption, high efficiency and silent operation design. Large air volume and efficient heat dissipation bring you a great experience.
Ports & Buttons for GN34
- 1* Microphone & Headphone Jack
- 1*MicroSD Card Slot 1*Gigabit Ethernet
- 1*DC 12V Input 1*Power Button
- 1*Reset Hole 1*HDMI Port
- 1*VGA Port 1*USB 2.0 2*USB 3.0
Small But Powerful DeskMini PC
GN34 Mini PC is small but powerful -- easy to carry with, easy to pocket. Make you work or entertainment everywhere you want.
Wall-mounted Bracket Support
With the mount bracket available, GN34 is perfect for use in any business environment, also it saves your rooms. Tips: the wall mount has already been included in the package.
Minisforum GN34 Mini PC
Processor
Intel® Celeron® Processor J3455 , 4 Cores/4 Threads
(2M Cache, up to 2.3 GHz)
GPU
Intel® HD Graphics 500
Memory
LPDDR4 8GB (On Board)
Storag
eMMC 64GB (On Board)
Storage Expansion
1×M.2 2242 SATA SSD Slot (up to 1TB , SATA 3.0 6.0Gb/s)
1×SD Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi，BT4.2
Ethernet
1000Mbps LAN
Video Output
① HDMI Type Port
② VGA Type Port
Audio Output
HDMI, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×1，USB 3.0 Port×3 , SD Card Slot×1 , DC Jack×1
Ports & Buttons
1 * Microphone & Headphone Jack
1 * MicroSD Card Slot
1 * Gigabit Ethernet
1 * DC 12V Input
1 * Power Button
1 * Reset Button
1 * HDMI Port
1 * VGA Port
1 * USB 2.0
2 * USB 3.0
Power
DC 12V/2A (adapter included)
System
Windows 10 Pro
Launch Date
March-20
Product Dimension
120×120×27mm
Package Dimension
205×130×60mm
Net Weight
0.25/KGS
Launch Date
0.60/KGS
Package Cotent
1 * GN34 Mini PC
1 * Power Adapter
1 * HDMI Cable
1 * VESA Mount
1 * VESA Mount Screw Set
1 * User Manual
Q1: Can you upgrade the ram in the 6gb version?
A: Sorry that this mini pc can not upgrade the ram in the 6gb version. Hope it helps.
Q2: Will this auto power on after power failure?
A: If you have this need, you can achieve it by setting up the system.
Q3: Is it ok to play high bitrate 4k (25+ gb files) movies?
A: This Mini PC supports 4K HD movies (even 25GB files).
Q4: How do you install the m.2 ngff 2242 ssd card thanks
A: The manual shows you how to do it. Basically you peel off the rubber feet and use a small screwdriver to remove the 4 screws. The motherboard is one piece, but the M.2 slot is on the bottom, meaning you have to pull out the entire motherboard to access it. It's stuck in there pretty good so be careful removing it. You'll also need a very small screwdriver to access the M.2 pin, so make sure you have the right hardware first. Then you can simply slide in the SSD drive and reassemble everything. If you've ever built a computer, this is fairly easy to do, but if you've never built a PC it may be a little scary to upgrade. Takes about 20 minutes.
Q5: Can I download dvds to this computer?
A: You have to connect an external hard drive device to this mini computer to download anything because it barely has enough internal memory to download Windows 10 updates.
Q6: Can you use a remote control?
A: Yes, this GN34 mini pc can be used a remote control.
Q7: Will this accept a msata ssd?
A: This Mini PC solo accept SD Card (Support 128GB) and M.2 NGFF2242 SSD (up to1TB).
Customer Reviews
MINISFORUM X35G Mini PC
Regular price $479.90 Sale price $429.90-
Meet X35G
-
Features
-
Specification
-
FAQs & Test Report
X35G Mini PC
Top Features
Stronger Core & Memory
Intel 10nm Core Processors Turbo Frequency 3.4GHz
DDR4-3200MHz 16GB (Dual Channel pre-install)
X35G adopts Intel® CPU, compared to the 8th Gen Intel® Core i3-8130U and i3-8145U, the 10th Gen Intel® Core™ i3 has some significant improvements. It can achieve faster operation and reduce power consumption.
Supporting more faster system memory (RAM) and higher frequency speed. Minisforum is the first mini pc with built-in Optane Memory, which makes mini pc to increase the speed of boot, software loading and file loading. Even can speed up the speed of game loading, also boost your work more efficiency.
Faster Network Experience
X35G built-in Wi-Fi6: with the latest Wi-Fi 6 technology, you can surf the web at the speeds of 300MB/s, 2.77 times faster than 5G Wi-Fi speed. Also BlueTooth 5.1 pre-install, RJ45 Gigabit Ethernet×2, this makes this MiniPC a perfect soft routing machine.
More Storage expansion
1×2.5 inch SATA3.0 HDD or SSD Supported
1×M.2 2280 SATA SSD Supported
M.2 2280 NVME SSD (pcie3.0 4X) Supported
Intel Optane Memory Supported
Flexible storage, easy to expand, 2.5-inch HDDS large capacity with low cost, support NVMe SSD fast read.
Stronger Output Methods
Thunderbolt 3 (UBS-C) : 5K@60Hz
HDMI 2.0: 4K@60Hz
Display Port: 5K@60Hz
The MINISFORUM X35G has multiple input/output ports, providing multiple ports for different types of peripherals.
Thunderbolt™ 3 brings lightning speed and performance to USB-C, creating one thin, reversible compact port that delivers the fastest2, most versatile connection to any dock, display, or data device.
Dual RJ45 Support
【Dual RJ45 LAN Ports】X35G comes with two Gigabytes LAN ports, which provide you much more network usage, such as software router (Open WRT/DD-WRT/Tomato, etc.), firewall, NAT and network isolation, etc.
Multiple Interfaces
Multiple types of interface allow you to have fun with multi-screens, high-definition playbacks, and other functions.
Super Cooling Systems
This Mini PC effectively dissipates heat out of the casing. It is designed to be ready to handle 25W TDP CPU (two heat pipes of pure copper). There is a Heatsink with a Centrifugal (Blower) Fan.
The motherboard has another additional intelligent temperature control system to ensure heat dissipation execution under ordinary working conditions and it's maximum quietness. At the point when the CPU load increments to 100%, it will naturally speed up to rapidly release the heat. This will also give improved product execution and soundness.
Boost Your Work Effeiciently
X35G represents a new attempt and match. The addition of Optane not only heighten hard drive performance, but it also has both speed and capacity. It can increase the speed of your software loading and document reading faster. Greatly improve work efficiency and comfort, also get rid of unpleasant work experience caused by stalls and crashes. Besides, X35G comes with Thunderbolt 3 and supports 5K video output. HDMI 2.0 supports 4K at 50FPS and 60FPS frame rates and expands the bandwidth to 18Gbps.The transmission speed of Thunderbolt 3 is 40GB/S.
Good Companion at Home or Office
The VESA mount is all set for easy installation on the back of televisions or monitors compatible with VESA, which allows X35G to turn into a home or office-friendly device.
Product Comparison
Application Scenarios
What's in the Box
Features & Functions for X35G
High Definition 4K Triple Displays
X35G Mini PC brings you ultra-realistic 4K UHD visuals with incredible clarity and maximum productivity in your workflow with excellent triple display solutions using HDMI with 5K@60Hz, DisplayPort as well as USB-C output. You can connect multiple screens in the same time for more efficiency.
Large Capacity and Storage Upgradable
X35G support DDR4-3200MHz 16GB (Dual Channel pre-installed), Optane™ Memory, 1TB HDD. It's easy to install the storage even if it's the first for you to add a storage.
Interfaces and Multiple Network Activities
Great choice for multiple commercial and industrial network activities. It's a ideal helper which can be widely used for Home Theater, Office Work, Meeting, Education, Projector Monitoring, Host, Printer, Media Equipment, Digital Signboard, also it's powerful enough for games and PS etc..
Ports & Buttons for X35G
- RJ45 Gigabit Ethernet Port x2
- USB 3.1 Port (Gen2, Blue) x2
- Display Port (5K@60Hz) x1
- HDMI 2.0 (4K@60Hz) x1
- Microphone Jack x1
- Kensington Lock x1
- Power Button x1
- TF Card Slot x1
- USB 2.0 Port x2
- DC 19V/1.9A x1
- Digital MIC x1
- Reset Hole x1
Mini Size but Powerful Mini PC
- 10th 10nm Gen Intel® Core™ i3
- Intel® UHD Graphics
- DDR4-3200MHz 16GB (Dual channel Onboard)
- NVME SSD (PCle3.0 4X)
- Intel® Optane™ Memory supported
- Intel® WIFI6 AX200，BT 5.1 pre-install
- Thunderbolt 3 5K / 60Hz
- RJ45 Gigabit Ethernet×2
Wall Mount Support
The wall mount bracket is already included in the package. And it's easy to be fixed on the back of the monitor or TV. Saving your space and keep your desk tidy.
Minisforum X35G Mini PC
Processor
Intel® Core™ i3-1005G1 Processor, 2 Cores/4 Threads
(4M Cache, up to 3.40 GHz)
GPU
Intel® UHD Graphics(300MHz- 900MHz)
Memory
DDR4 3200MHz 16GB (On Board Dual channel)
Support Optane™ Memory
Storage
M.2 2280 256GB/512GB PCIe SSD
Storage Expansion
1×M.2 2280 SATA SSD Slot (up to 1TB , SATA 3.0 6.0Gb/s)
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
1×TF Card Slot (up to 128GB)
Wireless Connectivity
M.2 2230 WIFI support (Intel® WIFI6 AX200，BT 5.1 pre-install)
Ethernet
1000Mbps LAN
Video Output
① HDMI 2.0(4K@60Hz)
② DisplayPort(5K@60Hz)
③ USB-C Port(Thunderbolt 3 , 5K@60Hz)
Audio Output
HDMI 2.0, DisplayPort, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×2, USB 3.1 Gen2 Port×2, USB 2.0 Port×2, TF Card Slot×1, DC Jack×1, MIC×1, Digital MIC×1
Ports & Buttons
2x RJ45 Gigabit Ethernet Port
2x USB 3.1 Port (Gen2, Blue)
1x Display Port (5K@60Hz)
1x HDMI 2.0 (4K@60Hz)
1x Microphone Jack
1x Kensington Lock
1x Power Button
1x TF Card Slot
2x USB 2.0 Port
1x DC 19V/1.9A
1x Digital MIC
1x Reset Hole
Power
DC 19V(adapter included), or via USB-C Port
System
Windows 10 Pro
Launch Date
November-20
Product Dimension
136×121×39 mm
Package Dimension
163×152×103mm
Net Weight
0.55/KGS
Launch Date
1.05/KGS
Package Cotent
1 * Minisforum X35G Mini PC
1 * Power Adapter
1 * HDMI Cable
1 * Display Port Cable
1 * USB Cable
1 * Mounting Bracket
1 * User Manual
Q1. When will X35G be shipped and how long to ship to me?
A: Hi, the shipping time for X35G will be the middle of December. And it usually takes 3~7 business day to deliver.
Q2. Where it shipped from?
A: Hi, as X35G is our new product, it will be shipped from China.
Q3. If it's Windows OS pre-installed?
A: Hi, yes, X35G is Windows 10 Pro pre-installed.
Q4. Will I need to pay custom duties or taxes on my orders?
A: Items shipped from all our warehouses are not subject to export taxes. However, if you are shipping an item from one county to another (shipped from China), you may be subject to pay local taxes and custom duties on said item. The customer is solely responsible for these expenses.
Q5. What do you mean about the three options for the configuration of X35G?
A: Hi, there are three types of X35G. DDR4 3200MHZ 16GB + PCIE3.0 256GB / DDR4 3200MHZ 16GB + PCIE3.0 512GB / LPDDR4 3200MHZ 16GB + Optane 16GB+WD 1T HDD, if you choose the 256 or 512GB SSD, a 16GB RAM and a 256GB or 512GB SSD will be shipped to you; or a 16GB RAM + Optane 16GB + 1TB HDD will be shipped to you.
Minisforum GN31 Mini PC
Regular price $189.00【Powerful J3160 Processor】Powered by Intel Celeron J3160 HD Graphics with Windows 10 Pro pre-installed, offering enterprise-class management and security that is suitable for multiple applications.
【Faster Speed Better Cooling System】Equipped with 128GB PCI-E M.2 NVMe 2280 SSD, 5.6 times faster than eMMC. The TDP 6W restriction has been unlocked and the TDP threshold has been increased to 9W, in this case, the CPU could load 100% for a long time without reducing the frequency.
【Extensible Memory】4 USB Ports available, 1 TF card slot, built-in SATA 3.0 connector(extensible 2.5-inch HDD) and NVMe 2280 SSD (up to 1TB). Windows can be upgraded without problems, and it also can storage various movies, TV shows so that you could enjoy your entertainment time whenever you are free.
【Dual Monitor Supportable】HDMI and VGA ports, two monitors can be operated at the same time, increase working efficiency and more fun for amusement.
-
Features and Benefits
-
J3160 SPEC
-
J3710 SPEC
-
FAQs & Test Report
This GN31 Mini PC is a compact PC, which offers enterprise-class management and security that is suitable for multiple applications. The slim design also features a detachable extension bay for enlarging storage–install SSD and HDD, which offers enhanced computing power and full connectivity.
Featured with sufficient I/O interfaces, it has high speed data access, plenty of storage, stable low-power processor with powerful Linux system, making GN31 a perfect product for industral automatic control
The GN31 Mini PC aims at delivering the maximum product performance without any performance losses.
Features & Functions for GN31 Mini PC
Industrial and Commercial Applications
GN31 Mini PC is a ideal device for multiple industrial and commercial applications. It can be used for TV, Prejector, Minitor, Monitor Equipment, Printer etc.
Fluent 4K Video Streaming
With HDMI & VGA, it's convenient and easy to connect with other device. Bring you big fun while playing games, watching movies or other entertainment with friends and family.
Large Capacity & Expanded Storage
Easy to upgrade to a higher storage and give you a larger capacities to ensure you have enough storage to use. Tips: 2.5 inch HDD and NGFF M.2 2280 in the picture are not included. It requires an additional purchase.
High Efficient & Silent Design
GN31 Mini PC is low comsumption, high efficiency and silent operation design. Large air volume and efficient heat dissipation bring you a great experience.
Ports & Buttons for GN31
- 1* Microphone & Headphone Jack
- 1* MicroSD Card Slot 1* HDMI Port
- 1* Gigabit Ethernet 1* VGA Port
- 1* DC 12V Input 2* USB 3.0
- 1*Power Button 1* Reset Button
- 2* USB 2.0
Wall-mounted Bracket Support
With the mount bracket available, the slim GN31 is perfect for use in any business environment, also it saves your rooms. Tips: the wall mount has already been included in the package.
Minisforum GN31 (J3160) Mini PC
Processor
Intel® Celeron® Processor J3160 , 4 Cores/4 Threads
(2M Cache, up to 2.24 GHz)
GPU
Intel® HD Graphics 400
Memory
LPDDR3 4GB (On Board)
Storag
M.2 2280 128GB PCIe SSD
Storage Expansion
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
1×TF Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi，BT4.2
Ethernet
1000Mbps LAN
Video Output
① HDMI Type Port
② VGA Type Port
Audio Output
HDMI, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×1, USB 3.0 Port×2, USB 2.0 Port×2, TF Card Slot×1, DC Jack×1
Ports & Buttons
1* Microphone & Headphone Jack
1* MicroSD Card Slot
1* Gigabit Ethernet
1* DC 12V Input
1* Power Button
1* Reset Button
1* HDMI Port
1* VGA Port
2* USB 2.0
2* USB 3.0
Power
DC 12V/3A (adapter included)
System
Windows 10 Pro
Launch Date
April-19
Product Dimension
120×120×36mm
Package Dimension
205×130×60mm
Net Weight
0.26/KGS
Launch Date
0.69/KGS
Package Cotent
1 * Minisforum GN31 (J3160) Mini PC
1 * Power Adapter
1 * Mini DP Cable
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Minisforum GN31 (J3710) Mini PC
Processor
Intel® Pentium® Processor J3710 , 4 Cores/4 Threads
(2M Cache, up to 2.64 GHz)
GPU
Intel® HD Graphics 405
Memory
LPDDR3 4GB (On Board)
Storag
M.2 2280 128GB SATA SSD
Storage Expansion
1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
1×TF Card Slot (up to 128GB)
Wireless Connectivity
IEEE 802.11ac Dual-Band Wi-Fi，BT4.2
Ethernet
1000Mbps LAN
Video Output
① HDMI Type Port
② VGA Type Port
Audio Output
HDMI, 3.5mm Audio Jack
Peripherals Interface
RJ45 Gigabit Ethernet Port×1，USB 3.0 Port×2 , USB 2.0 Port×2 , TF Card Slot×1 , DC Jack×1
Ports & Buttons
1* Microphone & Headphone Jack
1* MicroSD Card Slot
1* Gigabit Ethernet
1* DC 12V Input
1* Power Button
1* Reset Button
1* HDMI Port
1* VGA Port
2* USB 2.0
2* USB 3.0
Power
DC 12V/3A (adapter included)
System
Windows 10 Pro
Launch Date
July-20
Product Dimension
120×120×36mm
Package Dimension
205×130×60mm
Net Weight
0.26/KGS
Launch Date
0.69/KGS
Package Cotent
1 * Minisforum GN31 (J3710) Mini PC
1 * Power Adapter
1 * Mini DP Cable
1 * HDMI Cable
1 * Mounting Bracket
1 * User Manual
Q1: Two questions. How do I get into BIOS and how I put in a 2,5 HDD?
A: First question press DEL key for CMOS and F11 for booting media selection; Second in the upper case space one extra 2.5" sata socket connector exists.
Q2: If I plan to run linux on this, is the windows 10 license transferable to another PC?
A: Sorry that the Windows license can't be transferred to another PC, thanks.
Q3: POE- can this unit be powered by poe?
A: Sorry that this item doesn't support powered by POE,thanks.
Q4: For the model gn31 mini pc intel celeron j3160 processor. is the 4gb of lpddr3 upgradabe? if so, how many slots are available?
A: Sorry that the RAM of the GN31 Mini PC can't be upgraded, but you could expand the storage by installing SSD and HDD, thanks.
Q5: Can the tdp unlocker be turned off to help reduce the heat from the cpu?
A: It needs to update the BIOS. If you need it, you could contact us by minisforumtech@gmail.com, but the performance will be reduced once the tdp unlocker be turned off.
Q6. Will I need to pay custom duties or taxes on my orders?
A: Items shipped from all our warehouses are not subject to export taxes. However, if you are shipping an item from one county to another (shipped from China), you may be subject to pay local taxes and custom duties on said item. The customer is solely responsible for these expenses.
