AMD Ryzen
MINISFORUM DeskMini DMAF5
Regular price $399.00-
How It Works
-
Features and Benefits
-
SPEC & DESC
-
FAQs
-
Test Report
Introducing The MINISFORUM
For a long time, Intel® Nuc is known for its excellent performance and light size. It has always been the representative of Mini PC, leading the design of industry products, and is regarded as the king of minis! But it was criticized by fans for the slow performance improvement!
With the release of the AMD® Ryzen ™ Core Series, the Ryzen™ is now equipped with more cores, a stronger display card as well as having a quick response time. With this, it is made suitable for both work and entertainment as it enables you to complete your desired tasks efficiently.
DMAF5 is the first AMD® product designed by our company. Therefore, we have received official support from AMD®. We have listened to the constructive opinions of a large number of customers in the hope that it can set a new benchmark for professionalism. We are committed to creating innovative next-generation mini pc.
AMD ® Ryzen ™ 5 processor, 4 cores / 8 threads
Equipped with Radeon™Vega 8 Graphics 8 Cores Graphics
Brings a shocking visual effect
Max Turbo Frequency 3.7GHz
Unlocked the TDP, and No CPU throttling under 100% load for 24 hours
Our Mini PC is designed with a press and pop-up clasp, which makes it easy to install additional memory, SSD, HDD and Wi-Fi.
a. Dual channel (SODIMM Slots×2)
Dual-channel RAM is a version of multi-channel memory. All versions of multi-channel RAM increase data transmission speed by adding more communication channels between memory and memory controller. The transmission speed is faster than single channel.
b. M.2 2280 NVMe SSD Slot ×1
Support ultra-fast NVMe SSD, you will be able to run the operating system and games faster.
c. 2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s) ×1
You can add low-cost, large-capacity hard drives, enjoy the fun of DIY.
Intel® AX200 WLAN belongs to the AX-22260 family, code-named "Cyclone Peak", supports WiFi 6 technology (802.11ax) standard, integrates Bluetooth 5.0 module, supports 5GHz / 2.4GHz dual frequency and multi-user 2x2 MIMO (MU-MIMO), peak bandwidth It is 2.4Gbps, which is at least 37% higher than the current 802.11ac rate. WiFi5 802.11ac standard supports 160Mhz bandwidth.
The MINISFORUM mini PC drives up to three independent displays with incredible clarity and maximum productivity in your workflow with excellent triple display solutions using HDMI, DisplayPort as well as USB-C output.
【Dual RJ45 LAN Ports】DMAF5 comes with two Gigabytes LAN ports which provide you much more network usage, such as software router(OpenWRT/DD-WRT/Tomato, etc.), firewall, NAT and network isolation, etc.
The AMD® Ryzen5 3550H processor has a default TDP of 15W, and the power consumption of 15W limits its performance. AMD® officially allows a maximum power consumption of 35W. Of course, extremely clever optimization is required to achieve this goal. Therfore, we have made the following efforts:
a. Use a larger turbofan.
b. Add a thick thermally conductive copper tube and spray graphene on the heat dissipation module.
C. Equipped with power adapter, the maximum power consumption is 65W.
VESA Bracket——The VESA mount is ready to for the easy installation on the back of the VESA compatible televisions TV or monitors.
Multiple types of interface allows bring you to have fun with multi-screens, high-definition playbacks and other functions.
Deskmini DMAF5 Testing Report
1.Performance comparison of competitive products CPU&GPU
AMD Ryzen®5 processor, 4 cores / 8 threads，Equipped with Radeon™Vega 8 Graphics 8 Cores Graphics，Processor Base Frequency，Max Turbo Frequency 3.7GHz.CPU & GPU, with performance significantly higher than Intel® i5 8250U, higher than Intel® i7 8550U, and the same as Intel® i5 8259U.
2. Temperature test
• Thanks to super cooling, TDP can be unlocked for higher performance. The following results were tested using AIDA64. • AIDA64 test: stress test CPU / GPU / memory ... 100% load monitoring, for TDP 25W Unlocker, the temperature is maintained at about 61 ° C, the CPU frequency still performs best; for TDP 35W Unlocker, the temperature is maintained at At 75 ° C, the CPU frequency is increased by 0.55Ghz.
• The comparative test model uses the Intel Core® i5 8259U processor with a basic frequency of 2.3 GHz and a maximum turbo frequency of up to 3.80 GHz. Without TDP Unlocker and poor heat dissipation conditions, it is unable to fully utilize the better performance of the CPU.
3. 3DMARK Stress Test
• The following results were tested using 3DMARK 13 • Test items: [ Time Spy Stress Test ] • Test result: 99.3% PASSED.
4. 3DMARK11 TEST
• The DeskMini DMAF5 and the i7 CPU models on the market were tested and compared with 3DMARK11:
5. PCMark 10 TEST
CineBench is a very convincing test system for CPU and graphics card, the latest version is R20. Compared with the maximum 16 cores of R11.5 version, the R15 version can support up to 256 logical cores. In addition, the new version also strengthens the investigation of shaders, anti-aliasing, shadows, lights, and reflection blur. The detection is more accurate.
• TDP 25W =3503
• TDP 35W =3893
6. 3DMARK Night Raid TEST
• TDP 25W =5722
• TDP 35W =6528
DMAF5 Mini PC -- New NUC Killer
Powerful Mini PC backed up by the ryzen 5 3550H and radeon™vega 8 graphics. Upgrade-friendly & Windows 10 Pro pre-installed, intel®Wi-Fi6, BT5.1 and triple output. Seamlessly multitask with efficiency.
a. Dual channel (SODIMM Slots×2)
Dual-channel RAM is a version of multi-channel memory. All versions of multi-channel RAM increase data transmission speed by adding more communication channels between memory and memory controller. The transmission speed is faster than single channel.
b. M.2 2280 NVMe SSD Slot ×1
Support ultra-fast NVMe SSD, you will be able to run the operating system and games faster.
c. 2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s) ×1
You can add low-cost, large-capacity hard drives, enjoy the fun of DIY.
Features & Functions for DMAF5
High Definition 4K Triple Displays
DMAF5 Mini PC brings you ultra-realistic 4K UHD visuals with incredible clarity and maximum productivity in your workflow with excellent triple display solutions using HDMI, DisplayPort as well as USB-C output. You can connect multiple screens in the same time for more efficiency.
Flexible DIY Upgrade-Friendly
Our Mini PC is designed with a press and pop-up clasp, which makes it easy to install additional memory, SSD, HDD and Wi-Fi.
Multiple Application Options
Great choice for multiple commercial and industrial network activities. It's a ideal helper which can be widely used for Home Theater, Office Work, Meeting, Education, Projector Monitoring, Host, Printer, Media Equipment, Digital Signboard etc.
Ports & Button for DMAF5:
- RJ45 Gigabit Ethernet Port×2
- USB3.1 Port×1 (Gen1, Yellow)
- USB3.1 Port×3 (Gen2 , Blue)
- USB-C Port×1(Gen2)
- HDMI 2.0×1
- Display Port×1
- Audio Jack x 1
- Digital MIC×1
- Clear CMOS
Small but Powerful Mini PC
- AMD Ryzen 5 3550H
- Radeon Vega 8 Graphics
- Silent fan & Unlock TDP 25W/35W
- Windows 10 Home & Wifi 6 pre-installed
- DDR4 8GB×1 Dual channel (SODIMM Slots×2)
- Upgrade-friendly
- Support 3 monitors at the same time streaming in 4K@60Hz
- 2.5-inch SATA SSD
- M.2 2280 NVMe SSD (PCIE 4X)
Wall Mount Support
The wall mount bracket is already included in the package. And it's easy to be fixed on the back of the monitor or TV. Saving your space and keep your desk tidy.
- 【Excellent Processor and OS】: equipped with AMD Ryzen 5 3550H and Windows 10 Pro pre-installed, bringing excellent experience of the Internet and Office applications, such as TV, Media player, Monitor, Projector, Printer and other equipment.
- 【Silent Fan & & Unlock TDP 25W/35W 】: Very Silent with great performance, this mini pc adopts energy-efficient components and good cooling system, there is little noise during operating and plays 4K video smoothly. An ideal mini pc for home office, Internet surfing, watching movies, or simply browsing the web.
- 【Large Capacity & Friendly-upgraded】: DMAF5 is 8GB DDR4 Dual channel (SODIMM Slots×2) + 256GB SSD + 2.5 inch SATA HDD, Gigabit Ethernet LAN 1000M, M.2 2230 WIFI Support (Intel® WIFI6 AX200 , BT5.1 pre-install), Triple Screens ensure smooth navigation, responsive work processes and comfortable handling of apps and files. It’s the base operating frequency 2.1 GHz/s rising to a 3.7 GHz in burst mode.
- 【Certifications and Service】: Obtained FCC, CE, ROSH, C-TICK certifications. 1-year warranty, 1 month free return, get after-sale service support within 7X24 hours.
Package Includes:
- 1* MINI PC
- 1* HDMI Cable
- 1* USB Cable
- 1* Power Adapter
- 1* English Manual
- 1* Wall Mount Bracket
Ports & Button:
- RJ45 Gigabit Ethernet Port×2
- USB3.1 Port×1 (Gen1, Yellow)
- USB3.1 Port×3 (Gen2 , Blue)
- USB-C Port×1(Gen2)
- HDMI 2.0×1
- DisplayPort×1
- Audio Jack x 1
- Digital MIC×1
- Clear CMOS
Q1. When will DMAF5 be shipped and how long to ship to me?
A: Hi, the shipping time for DMAF5 will be the end of September. And it usually takes 3~7 business day to deliver.
Q2. Where it shipped from?
A: Hi, as DMAF5 is our new product, it will be shipped from China.
Q3. If it's Windows OS pre-installed?
A: Hi, yes, DMAF5 is Windows 10 Pro pre-installed.
Q4. Do I need to pay the shipping fee or tax for the product?
A: Hi, except the cost of the product itself, there is no need to pay additional tax/fee. Free shipping is offered to you at the same time.
Minisforum UM300 Mini PC
Regular price $299.00-
Features and Benefits
-
Specifications
-
Descriptions
-
Test Report
AMD Ryzen 3 3300U Windows 10 Home Mini PC
UM300 mini PC is equipped with the AMD Ryzen 3 3300U processor.
It delivers up to 50% better performance than previous generation processors and smoothly handles heavy compute tasks,
and it performs daily PC work smoothly with its reliable performance. The small body achieves the same performance as a desktop.
Upgrade-friendly Design
Versatile Storage Options
Flexible Dual-channel
The UM300 mini PC is designed with press and pop-up clasp, so you can easily install additional memory, SSD, HDD.To add more, push down the positions shown with both hands at the same time to pop out the cover.
M.2 2280 128GB SATA SSD is pre-installed and can be replaced with up to 2TB SSD. Supporting ultra-fast SSDs, you will be able to run the operating system and games faster and more efficient.
Memory has dual channel (SODIMM Slot x2), 8GB 2400MHz RAM is pre-installed and can be updated to 32GB each. The data transmission speed is improved by adding memory and speed is faster than single channel.
Features & Functions for UM300
Multiple Applications Support
UM300 Mini PC is a wisdom idea for multiple commercial applications. It can be widely used for Home Theater, Office Work, Meeting, Education, Projector Monitoring, Host, Printer, Media Equipment, Digital Signboard etc.
High Definition 4k Dual Display
With high definition 4k dual display, UM300 mini pc provides you more frequent movie experience and make your work more efficient via HDMI port, mini display port and USB-C port.
Large Capacity and Extended Storage
- Memory: DDR4 8GB×1 Dual channel (SODIMM Slots×2)
- Storage: M.2 2280 128GB SATA SSD
- Storage Expansion: 1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s)
Package Included
- 1* UM300 MINI PC
- 1* Power Adapter
- 1* HDMI Cable
- 1* DP Cable
- 1* Wall Mount
- 1* English Manual
Buttons & Ports for UM300 Mini PC
- 1x HDMI 2.0
- 1x Mini DP
- 2x RJ45 Port
- 1x Clear CMOS
- 1x Power Switch
- 1x Mini DP
- 1x USB-C
- 1x 3.5mm Audio Jack
- 1x DC Port (19V/3A)
- 1x Reset Hole
- 3x USB 3.1(Gen2, blue)
- 1x Digital Microphone Jack
- 1x USB 3.1 (Gen1, yellow, shutdown charge)
Wall Mount Included for Saving Space
The Wall Mount is included in the package, you could fix it on your back of the TV or monitor, which can save your room and make your desktop tidy and neat.
| Processor |
AMD Ryzen™ 3 3300U , 4 Cores/4 Threads (Total L2 Cache 2MB , Total L3 Cache 4MB , Base Clock 2.1 GHz , up to 3.5 GHz) |
| GPU | Radeon™ Vega 6 Graphics (Graphics Frequency 1200 MHz) |
| Memory | DDR4 8GB×1 Dual channel (SODIMM Slots×2) |
| Storage | M.2 2280 128GB/256GB/512GB SATA SSD |
| Storage Expansion | 1×2.5 inch SATA HDD Slot (SATA 3.0 6.0Gb/s) |
| Wireless Connectivity | M.2 2230 WIFI Support (Intel® WIFI6 AX200 , BT5.0 pre-install) |
| Video Output | ① HDMI 2.0(4K@60Hz)，② DisplayPort(4K@60Hz) , ③ USB-C Port(4K@60Hz) |
| Audio Output | HDMI 2.0 , DisplayPort , USB-C Port , 3.5mm Audio Jack |
| Peripherals Interface |
RJ45 Gigabit Ethernet Port×2 , USB3.1 Port×1(Gen1 , 2.0A Max output , shutdown charging , Yellow) , USB3.1 Port×3(Gen2 , Blue) , USB-C Port×1(Gen2) , Digital MIC×1 , Clear CMOS |
| Power | DC 19V/3A (adapter included) |
| Feature | RTC wake up/Wake on Lan/Power on auto power on (BIOS setting)/Network boot |
| Launch Date | July-20 |
| Product Dimension | 128×127×46mm |
| Package Dimension | 158×158×100mm |
| Net Weight | 0.55/KGS |
| Gross Weight | 1.40/KGS |
- 【Superior Performance】UM300 Mini PC pre-install Windows 10 Home pre-installed (supports Linux and Chromium OS), AMD Ryzen 3 3300U , 4 Cores/4 Threads (Total L2 Cache 2MB , Total L3 Cache 4MB , Base Clock 2.1 GHz , up to 3.5 GHz) processor Brings a shocking visual effect.
- 【Large capacity】DDR4 8GB×2 Dual channel (SODIMM Slots×2, memory can be converted to 16GB each) + M.2 2280 128GB SATA SSD storage (up to 2TB upgradeable).
- 【Expandable Storage】Designed with Dual channel (SODIMM Slots×2),M.2 2280 SATA SSD slot ×1,2.5' SATA HDD Slot (SATA 3.0 6.0Gb/s) ×1,witn press and pop-up clasp, which makes it easy to install additional memory/SSD/HDD.
- 【Triple Display Output】Installed with Radeon Vega 6 graphics (graphics frequency 1200 MHz), drives up to 3 independent displays with incredible clarity and maximum productivity in your workflow with excellent triple display solutions using HDMI 2.0
- 【What you get】 1x UM300 mini PC, 1x bracket, 1x mini DP cable, 1x HDMI cable (60 cm), 1x power supply, 1x manual. Note: The Mini DP connector does not support Mini DP to DVI / HDMI adapter, only Mini DP to VGA adapter. ***Each product includes LIFETIME technical support, a worry-free 30-day return and a 1-year after-sales service
- 【Warranty & Service】: one year warranty, one month free return, get after-sale service support within 7X24 hours.
Package Includes:
- 1* UM300 MINI PC
- 1* US Power Adapter
- 1* HDMI Cable
- 1* DP Cable
- 1* Wall Mount
- 1* English Manual
Ports & Button:
- 2* USB 3.0 port
- 1* display port
- 1* LAN port
- 1* Port Input
- 1* HDMI Port
- 1* kensington Lock
- 1* Power Button
- 1* Reset Button
- 1* Reset Hole
- 1* Digital MIC
- 2* USB 3.1
- 1* USB-C Port.
